Mitsubishi Diesel Power Generator Set Dg Mhi Genset S12r-Ptaa2 1200kw 1500kVA

Mitsubishi Diesel Power Generator Set Dg Mhi Genset S12r-Ptaa2 1200kw 1500kVA

Quick Details:

After-sales Service: After Sales Service and Guarantee
Warranty: 12 Months or 1200 Hours
Type: Self-Starting Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
WT-M1650
Output Type
AC Three Phase
Speed
Speed
Conditions of Use
Land Use
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
AC Rotating Exciter
Output
400/230V, 380/220V, 440/220V, 415/240V, 480/277V
Phase
Single or Three Phase
Frequency
50Hz/60Hz
Engine Speed
1500rpm/1800rpm
Battery Volatge
12V/24V
Aspiration Engine Type
Turbocharged
Cooling System
Water Cooled
Governing Type
Electrical Starting GAC
Compress Ratio
16.5:1
Voltage Regulator
AVR Auto Voltage Regulator
Voltage Regulation Maintanined
Within 0.5%
Alternator
Bruxhless, Self Exciting, 100% Copper
Insulation Class
Class “H”
Auto Transfter Switch
Optional ATS
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Including Wooden Package
Specification
6000x2500x2500MM
Trademark
WINTPOWER
Origin
China
HS Code
85021310
Production Capacity
8000

Product Description

Mitsubishi Diesel Power Generator Set Dg Mhi Genset S12r-Ptaa2 1200kw 1500kVA 400/230V 380/220V 415/240V 50Hz 60Hz

WT-ME MITSUBISHI SERIES SPECIFICATION 50HZ @ 1500RPM
Genset Model 50HZ PF=0.8 400/230V 3Phase 4Wire Engine Model cyl displacement Battery Vol. Max power Governor Open Type Dimension
Standby Power Prime Power Cons 100%(L/H)
KVA/KW KVA/KW L V KW L×W×H(MM) Weight KG
WT-MEZ688 688/550 625/500 138 S6R2-PTA-C 6L 30 24 635 Elec. 3560*1410*1933 5210
WT-MEZ730 730/584 662.5/530 138 S6R2-PTA-C 6L 30 24 635 Elec. 3560*1410*1933 5210
WT-MEZ770 770/616 700/560 163 S6R2-PTAA-C 6L 29.96 24 710 Elec. 3870*1675*2134 5021
WT-MEZ825 825/660 750/600 163 S6R2-PTAA-C 6L 29.96 24 710 Elec. 3870*1675*2134 5021
WT-MEZ1375 1375/1100 1250/1000 266 S12R-PTA-C 12V 49.03 24 1190 Elec. 4540*1795*2510 9248
WT-MEZ1500 1500/1200 1375/1100 281 S12R-PTA2-C 12V 49.03 24 1285 Elec. 4585*2083*2537 9953
WT-MEZ1650 1650/1320 1500/1200 308 S12R-PTAA2-C 12V 49.03 24 1404 Elec. 4915*2202*2723 10613
WT-MEZ1850 1850/1480 1650/1320 310 S16R-PTA-C 16V 65.37 24 1590 Elec. 5211*1857*2700 11591
WT-MEZ1875 1875/1500 1700/1360 310 S16R-PTA-C 16V 65.37 24 1590 Elec. 5211*1857*2700 11591
WT-MEZ2050 2050/1640 1860/1488 418 S16R-PTA2-C 16V 65.37 24 1760 Elec. 5311*2590*2978 12258
WT-MEZ2200 2200/1760 2000/1600 432 S16R-PTAA2-C 16V 65.37 24 1895 Elec. 5689*2202*2723 12833
WT-MEE315 315/252 288/230 66 S6B-PTA2 6L 12.88 24 291 Elec. 3180*1350*1770 2858
WT-ME400 400/320 365/292 81 S6B3-PTA 6L 14.6 24 360 Elec. 3180*1350*1770 3196
WT-ME485 485/388 440/352 97 S6A3-PTA 6L 18.6 24 430 Elec. 3530*1350*1850 3863
WT-ME688 688/550 625/500 138 S6R2-PTA 6L 30 24 635 Elec. 3600*1520*2140 5122
WT-ME720 720/576 655/524 138 S6R2-PTA 6L 30 24 635 Elec. 3600*1520*2140 5122
WT-ME810 810/648 735/588 158 S12A2-PTA 12V 33.9 24 724 Elec. 4050*1630*2080 6370
WT-ME1100 1100/880 1000/800 227 S12H-PTA 12V 37.1 24 980 Elec. 4330*1760*2380 8358
WT-ME1375 1375/1100 1250/1000 266 S12R-PTA 12V 49 24 1190 Elec. 4560*2250*2380 9435
WT-ME1485 1485/1188 1350/1080 281 S12R-PTA2 12V 49 24 1285 Elec. 4560*2250*2380 9548
WT-ME1625 1625/1300 1475/1180 308 S12R-PTAA2 12V 49 24 1404 Elec. 5030*2230*2550 10835
WT-ME1815 1815/1452 1650/1320 310 S16R-PTA 16V 65.4 24 1590 Elec. 5450*2250*2530 12062
WT-ME1875 1875/1500 1700/1360 310 S16R-PTA 16V 65.4 24 1590 Elec. 5450*2250*2530 12340
WT-ME2050 2050/1640 1860/1488 418 S16R-PTA2 16V 65.4 24 1760 Elec. 5450*2250*2530 12475
WT-ME2200 2200/1760 2000/1600 432 S16R-PTAA2 16V 65.4 24 1895 Elec. 5780*2230*2550 13724
WT-ME2420 2420/1936 2200/1760 472.7 S16R2-PTAW 16V 79.9 24 2167 Elec. 5990*2230*2550 14404
WT-ME2500 2500/2000 2270/1816 472.7 S16R2-PTAW 16V 79.9 24 2167 Elec. 5990*2230*2550 14404
WT-ME MITSUBISHI SERIES SPECIFICATION 60HZ @ 1800RPM
Genset Model 60HZ PF=0.8 440/220V 3Phase 4Wire Engine specification Genset canopy data Genset open data
Standby Power Prime Power Cons 100%(L/H) Engine Model Cyl. Gov. Displacement(L) Dimention(MM) weight(KG) Dimention(MM) Weight(KG)
KVA/KW KVA/KW
WT-ME8 8.2/6.5 7.5/6 2.79 L3E-W461DG 3L Elec 0.952 1900*730*1130 625 1200*540*850 460
WT-ME13 12.5/10 11.5/9.2 4.27 S3L2-W461DG 3L Elec 1.318 1900*730*1130 625 1200*540*950 460
WT-ME26 26/21 23.5/19 9.06 S4Q2-Y365DG 4L Elec 2.505 1900*730*1130 700 1350*540*950 491
WT-ME35 35/28 32/26 11.42 S4S-Y365DG 4L Elec 3.331 2250*950*1280 835 1550*740*1250 693
WT-ME37 37/30 33.8/27 12.07 S4S-Y365DG 4L Elec 3.331 2250*950*1280 835 1550*740*1250 693
WT-ME44 44/35 40/32 14.92 S4S-Y3DT65DG 4L Elec 3.331 2250*950*1280 1090 1640*740*1250 890
WT-ME48 48/38 43.8/35 16.33 S4S-Y3DT65DG 4L Elec 3.331 2250*950*1280 1090 1640*740*1250 890
WT-ME330 330/264 300/240 93 S6B-PTA2 6L Elec 12.88 4350*1500*2260 4020 3180*1350*1770 2858
WT-ME360 360/288 325/260 100.9 S6B-PTA2 6L Elec 12.88 4350*1500*2260 4020 3180*1350*1770 2858
WT-ME395 395/316 360/288 106.9 S6B3-PTA 6L Elec 14.6 4350*1500*2260 4020 3180*1350*1770 3196
WT-ME440 440/352 400/320 118.8 S6B3-PTA 6L Elec 14.6 4350*1500*2260 4020 3180*1350*1770 3196
WT-ME500 500/400 450/360 137 S6A3-PTA 6L Elec 18.56 4650*1600*2260 5270 3530*1350*1850 3863
WT-ME525 525/420 475/380 144.6 S6A3-PTA 6L Elec 18.56 4650*1600*2260 5270 3530*1350*1850 3863
WT-ME535 535/428 488/390 148.6 S6A3-PTA 6L Elec 18.56 4650*1600*2260 5270 3530*1350*1850 3863
WT-ME600 600/480 550/440 168.5 S6R-PTA 6L Elec 24.51 4950*1800*2514 5630 3560*1410*1933 5210
WT-ME650 650/520 594/475 181.9 S6R-PTA 6L Elec 24.51 4950*1800*2514 5630 3560*1410*1933 5210
WT-ME710 710/568 645/516 197.7 S6R-PTA 6L Elec 24.51 4950*1800*2514 5630 3560*1410*1933 5210
WT-ME850 850/680 775/620 237.5 S12A2-PTA 12V Elec 33.93 20GP container 12750 4050*1630*2080 6370
WT-ME880 880/704 800/640 245.1 S12A2-PTA 12V Elec 33.93 20GP container 12750 4050*1630*2080 6370
WT-ME1170 1170/936 1063/850 313.4 S12H-PTA 12V Elec 37.11 20GP container 12750 4330*1760*2380 8358
WT-ME1200 1200/960 1100/880 324.4 S12H-PTA 12V Elec 49.03 20GP container 12750 4560*2250*2380 9435
WT-ME1320 1320/1056 1200/960 351.6 S12R-PTA 12V Elec 49.03 20GP container 12750 4560*2250*2380 9435
WT-ME1415 1415/1132 1287/1030 377.1 S12R-PTA 12V Elec 49.03 20GP container 12750 4560*2250*2380 9435
WT-ME1470 1470/1176 1338/1070 404.9 S12R-PTA2 12V Elec 49.03 20GP container 12750 4560*2250*2380 9548
WT-ME1600 1600/1280 1450/1160 438.8 S12R-PTA2 12V Elec 49.03 20GP container 12750 4560*2250*2380 9548
WT-ME1788 1788/1430 1625/1300 477 S12R-PTAA2 12V Elec 49.03 20GP container 12750 5030*2230*2550 10835
WT-ME1925 1925/1540 1750/1400 509.5 S16R-PTA 16V Elec 65.37 40HQ container 20800 5450*2250*2530 12062
WT-ME2125 2125/1700 1925/1540 582.5 S16R-PTA2 16V Elec 65.37 40HQ container 20800 5450*2250*2530 12475
WT-ME2375 2375/1900 2150/1720 626 S16R-PTAA2 16V Elec 65.37 40HQ container 20800 5780*2230*2550 13724

A.STANDARD SUPPLY:1.Brand new CCEC/DCEC CUMMINS, MITSUBISHI, DEUTZ, DOOSAN, YUCHAI, KUBOTA, RICARDO, YANGDONG,water cooled diesel engine.2.Brand newSTAMFORD, LEROY SOMER or WINTsingle bearing 3 phase brushless alternator with 100% copper, IP23 and H insulation class.3. Standard 50ºC radiator with safety guard, engine driven fan mounted on skid4. DEEPSEA, COMAP, SMARTGEN controller brand with Auto/Manual start and AMF function5. DELIXI, CHINT or ABBbranded MCCB circuit breaker mounted.6. Heavy-duty fabricated steel based frame with convenient lifting, forklift pockets7. Complete set mounted on a based frame with anti-vibration mountings.8. Industrial 9 dB muffler exhaust system with blexible connects and bellows.9. Based frame with fuel, oil and coolant drain cocks for easy maintenance.10. 12/24V DC electric start system with free maintaining battery & floating battery charger.11. Standard with built-in fuel tank for 8 hours running. Canopy noise levels @7 meters with 70 dB12. Test report of generator, set of drawings and manuals. CE, ISO9001 approvedΔ OPTIONAL SUPPLY: 1.Weatherproof canopy / Soundproof canopy / Trailer-mounted2.Engine / Alternator Pre-heaters3.Auto load sharing & synchronizing panel4.Build-in ATS (Auto start & stop Main Failure (AMF)5.Large 12/24 hours fuel tank6.Power output socketsΔTESTING ITEMSWintpower factory inspection: the test items before delivery are mainly as follows:1.Parts faults testing2.Fuel tank pressure testing3.Bolt tightening torque testing4.Painting thickness testing5.Voltage bearing and insulation testing6.The noise level is tested by requested7.loadingtest range 25% 50% 75% 100% 110% 75% 50% 25% 0%ΔWintpower Silent typeDiesel Generator, advantagesas follows:1. Integrated interface with humanized and practicablydesign2. Super silentmaterial and treatment reach 70dBA@1M full load3. Steel material thickness2MM to 4MM,cut and fold by CNC4. New safe door handle, updated lock, bottom forkliftand top lift5. Aviation outtake connectorad operation LED light6. Free maintenance battery with floating charger8. 8-24hoursbase fuel tank with electrical fuel indicator9. Powder coating canopies afterchemistry treatment

GENSET STANDARD SPECIFICATION
Gensets model Power output(KVA) Power output (KW) Mitsubishi Engine Model Leroy somer Alternator
PRP ESP PRP ESP
WT-M1375 1250 1375 1000 1100 S12R-PTA-C LSA50.2M6
(1) Available in the following voltages:220V-240V AND 380V-415V(440V)-50HZ
(2) PRP:Prime Power-Continuous duty operation,under variable load 24/24-h-10% overload permissible 1 hour/12hours.
(3) Rating Definitions (Operation at Altitude1000m, Ambient temperature40ºC)Continuous Power.These ratings are applicable for supplying continuous electrical power (at variable load) in lieu of commercially purchased power.There is no limitation to the annual hours of operation and this model can supply 10% overload power for 1 hour in 12 hours.
Engine & Alternator
ENGINE–Industrial 4 stroke cooled diesel engine complete with air,fuel and oil filters,electric starting and charging equipment,engine protection against low water level.
ALTERNATOR–Brushless,self exciting,self regulation,sreen protected,drip proof rated in accordance with IEC60034.Voltage regulation maintainted within ±0.5% from no load to full load.between 0.8 lagging and unity.All standard voltages available.
COOLING–Radiator and colling fan complete with protection guards,designed to cool engine at specified output in air temperatures upto 45ºC,radiators suitable for higher temperatures are available.Low water level protection fitted as standard.
ELECTRICAL SYSTEM–24V upto.Axial type starter motor,battery charging alternator,high capacity lead acid battery,and battery tray mounted on the generator base frame,and heavy duty interconnecting cable with terminations.
EXHAUST SYSTEM--Heavy duty industrial exhauset silencer with flexible piping.
Technical Data Sheet
Generating sets model:
400V,50Hz,1500 rpm Genset Option Features
Engine Model: MitsubishiS12R-PTA-C ΔLow fuel level alarm shutdown
Type 12 V cylinder,4 cycle diesel ΔAutomatic Fuel Filling System
Aspiration Turbocharged inter-cooled ΔEngine oil feeding and drain pump
Bore/Stroke mm 170X180 ΔAuto Transfter Switch( ATS)
Compress the ratio 14.0 : 1 ΔParallel control panels
Cooling system Water-cooled ΔCircuit Breaker MCCB & ACB
100% Load Fuel Consumption g/kwh 197 ΔRemote Control Panel
Engine Speed/Frequency RPM/Hz 1500/50HZ Δweatherproof/soundproof Canopy
Rated Output kw/bHP 1080/1448 ΔTrailer type Gensets
Exhaust air flow (m3/min) 89 QUALITY STANDARDS
Coolant Capacity L 125 ISO9001:2000,ISO14000,ISO3046
Starting System Electric 24 volt DC ISO8528 BS4999
Displacement L 49.03 BS5514,AS1359,ICE34
Lubricant system Capacity L 180 CE Compliance
Battery Volatge / Capacity 24VDC Gensets Dimensions & Weight
Governing Type Electrical (GAC governor) Open type:L*W*H,mm
Exhaust Gas TemperatureºC 98 5382×2486×2931
Exhaust Gas flow m3/min 235 Silent type:L*W*H,mm
Noise level dBA@7m 85dBA(silent type) 40GP container
Alternator Technical data
Leroy somer
ΔBruxhless,self exciting Exciter Brushless
Δclass “H” insulation Cooling Fan Cast alloy aluminum
ΔStandard degree of protection is IP23 Bearing Single,double shielded
Δself regulating Windings 100% copper
ΔWith fan cooling Connection Type Reconnectable
ΔResist Humid grease Insulation Type Class H
ΔAC excitation,roating rectification tube Pitch 2/3
ΔStator grease insulation covered Amortisseur Winding Full
ΔRotator and exciation high polymer,Resist the corruption of oil and acid Voltage Regulator AVR R250
Voltage Regulator NL-FL ±0.5%
ΔRotator ballance is in accordance with BS5625 standard 12.5 Underspeed Protection Standard
Overexcitation Protection IP23
ΔHigh-quality lubrication sealed long-time bearing TIF (1960 Weightings) <50
ΔRotator sillicon steel close tight Exciation System AREP
Control Panel – DEEPSEA7320
The base mounted control panel in a vibration isolated sheet steel enclosure.The control panel is equipped as follows:
a)Instruments:Analogue Volmeter,Hours Run Meter.Water pressure Meter.
b) Controls:Emergency Stop Pushbutton,Volmeter Phase Selector Switch.
c) Control module:Standard collocation is DSE7320 Auto start .

Mitsubishi Diesel Power Generator Set Dg Mhi Genset S12r-Ptaa2 1200kw 1500kVA 400/230V 380/220V 415/240V 50Hz 60HzMitsubishi Diesel Power Generator Set Dg Mhi Genset S12r-Ptaa2 1200kw 1500kVA 400/230V 380/220V 415/240V 50Hz 60HzMitsubishi Diesel Power Generator Set Dg Mhi Genset S12r-Ptaa2 1200kw 1500kVA 400/230V 380/220V 415/240V 50Hz 60HzMitsubishi Diesel Power Generator Set Dg Mhi Genset S12r-Ptaa2 1200kw 1500kVA 400/230V 380/220V 415/240V 50Hz 60HzMitsubishi Diesel Power Generator Set Dg Mhi Genset S12r-Ptaa2 1200kw 1500kVA 400/230V 380/220V 415/240V 50Hz 60HzMitsubishi Diesel Power Generator Set Dg Mhi Genset S12r-Ptaa2 1200kw 1500kVA 400/230V 380/220V 415/240V 50Hz 60HzMitsubishi Diesel Power Generator Set Dg Mhi Genset S12r-Ptaa2 1200kw 1500kVA 400/230V 380/220V 415/240V 50Hz 60HzMitsubishi Diesel Power Generator Set Dg Mhi Genset S12r-Ptaa2 1200kw 1500kVA 400/230V 380/220V 415/240V 50Hz 60HzMitsubishi Diesel Power Generator Set Dg Mhi Genset S12r-Ptaa2 1200kw 1500kVA 400/230V 380/220V 415/240V 50Hz 60HzMitsubishi Diesel Power Generator Set Dg Mhi Genset S12r-Ptaa2 1200kw 1500kVA 400/230V 380/220V 415/240V 50Hz 60HzMitsubishi Diesel Power Generator Set Dg Mhi Genset S12r-Ptaa2 1200kw 1500kVA 400/230V 380/220V 415/240V 50Hz 60HzΔFAQWhat’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .ΔWINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useΔWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
