Yto Diesel Power Generator Set Dg Genset 125kVA 165kVA 220kVA

Yto Diesel Power Generator Set Dg Genset 125kVA 165kVA 220kVA

Quick Details:

After-sales Service: After Sales Service and Guarantee
Warranty: 12 Months or 1200 Hours
Type: Self-Starting Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
WT-YT248
Output Type
AC Three Phase
Speed
Speed
Conditions of Use
Land Use
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
AC Rotating Exciter
Genset Output
400/230V 380/220V 440/220V 415/240V 480/277V
Phase
Single or Three Phase
Frequency
50Hz/60Hz
Engine Speed
1500rpm/1800rpm
Battery Volatge
12V/24V
Aspiration Engine Type
Turbocharged
Cooling System
Water Cooled
Governing Type
Electrical Starting GAC
Compress Ratio
17.0:1
Voltage Regulaor
AVR Auto Voltage Regulator
Voltage Regulation Maintanined
Within 0.5%
Alternator
Brushless, Self Exciting, 100% Copper
Insulation Class
Class “H”
Auto Transfter Switch
Optional ATS
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Including Wooden Package
Specification
2300x980x1500MM
Trademark
WINTPOWER
Origin
China
HS Code
85021200
Production Capacity
8000

Product Description

Yto Diesel Power Generator Set Dg Genset 124kVA Lr4m3l-15 138kVA Lr6a3l-15 165kVA Lr6b3l-15 179kVA Lr6m3l-15 220kVA Ym6h4l-15 248kVA Ym6h4l-15Quick DetailsYTO diesel generator, YTO Generating set, YTO Genset, 20kva YTO generator, 25kva YTO generator, 30kva YTO generator, 40kva YTO generator, 50kva YTO generator, 100kw YTO generator, YTO power generator, YTO generator parts, Open type YTO generator, Silent YTO generator, YTO power station, Weichai diesel generator, Low price Genset, Cheap diesel generatorChina brand generator, generator price list China

WT-YTO YTO SERIES SPECIFICATION 50HZ @ 1500RPM
Genset Model 50HZ PF=0.8 400/230V 3Phase 4Wire Engine Model Alternator Model
Prime Power Standby Power Cons 100%(L/H)
KW/KVA KW/KVA
WT-YC34 28/34 25/31 YT3B2-15 YT3B2-D91F-U2 WT184G25
WT-YTO41 33/41 30/338 YT3A2Z-15 YT3A2Z-D91F-U2 WT184G30
WT-YTO55 44/55 40/50 LR4B5-15 LR4B5-D91F-U2 WT224G40
WT-YTO69 55/69 50/63 YT4B2Z-15 YT4B2Z-D91F-U2 WT224G58
WT-YTO72 57/72 52/65 LR4B3Z-15 LR4B3Z-D91F-U2 WT224G58
WT-YTO103 83/103 75/94 LR4M3L-15 LR4M3L-D91EF-U2 WT274G80
WT-YTO110 88/110 80/100 LR4M3L-15 LR4M3L-D88DF-U2 WT274G80
WT-YTO124 99/124 90/113 LR4M3L-15 LR4M3L-D88DF-U2 WT274G90
WT-YTO138 110/138 100/125 LR6A3L-15 LR6A3L-D91EF-U2 WT274G112
WT-YTO165 132/165 120/150 LR6B3L-15 LR6B3L-D91AEF-U2 WT274G128
WT-YTO179 143/179 130/163 LR6M3L-15 LR6M3L-D91AEF-U2 WT274G140
WT-YTO220 176/220 160/200 YM6H4L-15 YM6H4L-D119EF-U2 WT274G160
WT-YTO248 198/248 180/225 YM6H4L-15 YM6H4LF-D119EF-U2 WT274G180
WT-YTO275 220/275 200/250 YM6S4L-15 YM6S4L-D119EF-U2 WT274G200
WT-YTO303 242/303 220/275 YM6S4L-15 YM6S4LF-D119EF-U2 WT314G220
WT-YTO344 275/344 250/313 YM6S9L-15 YM6S9L-D119EF-U2 WT314G250
WT-YTO375 300/375 280/350 YM6S9L-15 YM6S9L-D119BEF-U2 WT314G280
WT-YTO413 330/413 300/375 YM6S9L-15 YM6S9LF-D119EF-U2 WT314G300
WT-YTO438 350/438 320/400 YM6S9L-15 YM6S9LF-D119AEF-U2 WT314G320
WT-YTO YTO SERIES SPECIFICATION 60HZ @ 1800RPM
Genset Model 60HZ PF=0.8 440/220V 3Phase 4Wire Engine specification
Prime Power Standby Power Cons 100%(L/H) Engine Model Alternator Model
KW/KVA KW/KVA
WT-YTO41 33/41 30/38 YT3B2-18 YT3B2-D91F-U2 WT184G25
WT-YTO44 35/44 32/40 YT3A2Z-18 YT3A2Z-D91F-U2 WT184G30
WT-YTO61 48/61 44/55 LR4B5-18 LR4B5-D91F-U2 WT224G40
WT-YTO74 59/74 54/68 YT4B2Z-18 YT4B2Z-D91F-U2 WT224G45
WT-YTO77 62/77 56/70 LR4B3Z-18 LR4B3Z-D91F-U2 WT224G45
WT-YTO110 88/110 80/100 LR4M3L-18 LR4M3L-D91EF-U2 WT224G68
WT-YTO124 99/124 90/113 LR4M3L-18 LR4M3L-D88DF-U2 WT274G90
WT-YTO144 115/144 105/131 LR6A3L-18 LR6A3L-D91EF-U2 WT274G90
WT-YTO172 138/172 125/156 LR6B3L-18 LR6B3L-D91AEF-U2 WT274G112
WT-YTO186 149/186 135/169 LR6M3L-18 LR6M3L-D91AEF-U2 WT274G112
WT-YTO248 198/248 180/225 YM6H4L-18 YM6H4L-D119EF-U2 WT274G160
WT-YTO261 209/261 190/248 YM6H4LF-18 YM6H4LF-D119EF-U2 WT274G160
WT-YTO303 242/303 220/275 YM6S4L-18 YM6S4L-D119EF-U2 WT274G200
WT-YTO316 253/316 230/288 YM6S4LF-18 YM6S4LF-D119EF-U2 WT274G200
WT-YTO385 308/385 280/350 YM6S9L-18 YM6S9L-D119EF-U2 WT314G240
WT-YTO413 330/413 300/375 YM6S9L-18 YM6S9L-D119BEF-U2 WT314G250
WT-YTO440 352/440 320/400 YM6S9L-18 YM6S9LF-D119EF-U2 WT314G280
WT-YTO440 352/440 320/400 YM6S9L-18 YM6S9LF-D119AEF-U2 WT314G300

A.STANDARD SUPPLY:1.Brand new CCEC/DCEC, DEUTZ, DOOSAN, YUCHAI, KUBOTA, RICARDO, YANGDONG,water cooled diesel engine.2.Brand newSTAMFORD, LEROY SOMER or WINTsingle bearing 3 phase brushless alternator with 100% copper, IP23 and H insulation class.3. Standard 50ºC radiator with safety guard, engine driven fan mounted on skid4. DEEPSEA, COMAP, SMARTGEN controller brand with Auto/Manual start and AMF function5. DELIXI, CHINT or ABBbranded MCCB circuit breaker mounted.6. Heavy-duty fabricated steel based frame with convenient lifting, forklift pockets7. Complete set mounted on a based frame with anti-vibration mountings.8. Industrial 9 dB muffler exhaust system with blexible connects and bellows.9. Based frame with fuel, oil and coolant drain cocks for easy maintenance.10. 12/24V DC electric start system with free maintaining battery & floating battery charger.11. Standard with built-in fuel tank for 8 hours running. Canopy noise levels @7 meters with 70 dB12. Test report of generator, set of drawings and manuals. CE, ISO9001 approvedΔ OPTIONAL SUPPLY: 1.Weatherproof canopy / Soundproof canopy / Trailer-mounted2.Engine / Alternator Pre-heaters3.Auto load sharing & synchronizing panel4.Build-in ATS (Auto start & stop Main Failure (AMF)5.Large 12/24 hours fuel tank6.Power output socketsΔTESTING ITEMSWintpower factory inspection: the test items before delivery are mainly as follows:1.Parts faults testing2.Fuel tank pressure testing3.Bolt tightening torque testing4.Painting thickness testing5.Voltage bearing and insulation testing6.The noise level is tested by requested7.loadingtest range 25% 50% 75% 100% 110% 75% 50% 25% 0%ΔWintpower Silent typeDiesel Generator, advantagesas follows:1. Integrated interface with humanized and practicablydesign2. Super silentmaterial and treatment reach 70dBA@1M full load3. Steel material thickness2MM to 4MM,cut and fold by CNC4. New safe door handle, updated lock, bottom forkliftand top lift5. Aviation outtake connectorad operation LED light6. Free maintenance battery with floating charger8. 8-24hoursbase fuel tank with electrical fuel indicator9. Powder coating canopies afterchemistry treatmentYto Diesel Power Generator Set Dg Genset 124kVA Lr4m3l-15 138kVA Lr6a3l-15 165kVA Lr6b3l-15 179kVA Lr6m3l-15 220kVA Ym6h4l-15 248kVA Ym6h4l-15Yto Diesel Power Generator Set Dg Genset 124kVA Lr4m3l-15 138kVA Lr6a3l-15 165kVA Lr6b3l-15 179kVA Lr6m3l-15 220kVA Ym6h4l-15 248kVA Ym6h4l-15Yto Diesel Power Generator Set Dg Genset 124kVA Lr4m3l-15 138kVA Lr6a3l-15 165kVA Lr6b3l-15 179kVA Lr6m3l-15 220kVA Ym6h4l-15 248kVA Ym6h4l-15Yto Diesel Power Generator Set Dg Genset 124kVA Lr4m3l-15 138kVA Lr6a3l-15 165kVA Lr6b3l-15 179kVA Lr6m3l-15 220kVA Ym6h4l-15 248kVA Ym6h4l-15Yto Diesel Power Generator Set Dg Genset 124kVA Lr4m3l-15 138kVA Lr6a3l-15 165kVA Lr6b3l-15 179kVA Lr6m3l-15 220kVA Ym6h4l-15 248kVA Ym6h4l-15Yto Diesel Power Generator Set Dg Genset 124kVA Lr4m3l-15 138kVA Lr6a3l-15 165kVA Lr6b3l-15 179kVA Lr6m3l-15 220kVA Ym6h4l-15 248kVA Ym6h4l-15Yto Diesel Power Generator Set Dg Genset 124kVA Lr4m3l-15 138kVA Lr6a3l-15 165kVA Lr6b3l-15 179kVA Lr6m3l-15 220kVA Ym6h4l-15 248kVA Ym6h4l-15Yto Diesel Power Generator Set Dg Genset 124kVA Lr4m3l-15 138kVA Lr6a3l-15 165kVA Lr6b3l-15 179kVA Lr6m3l-15 220kVA Ym6h4l-15 248kVA Ym6h4l-15Yto Diesel Power Generator Set Dg Genset 124kVA Lr4m3l-15 138kVA Lr6a3l-15 165kVA Lr6b3l-15 179kVA Lr6m3l-15 220kVA Ym6h4l-15 248kVA Ym6h4l-15Yto Diesel Power Generator Set Dg Genset 124kVA Lr4m3l-15 138kVA Lr6a3l-15 165kVA Lr6b3l-15 179kVA Lr6m3l-15 220kVA Ym6h4l-15 248kVA Ym6h4l-15Yto Diesel Power Generator Set Dg Genset 124kVA Lr4m3l-15 138kVA Lr6a3l-15 165kVA Lr6b3l-15 179kVA Lr6m3l-15 220kVA Ym6h4l-15 248kVA Ym6h4l-15ΔFAQWhat’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .ΔWINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useΔWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
