Weichai Kofo Ricardo Diesel Engine Power Generator Set Dg Genset 165kVA

Weichai Kofo Ricardo Diesel Engine Power Generator Set Dg Genset 165kVA

Quick Details:

After-sales Service: After Sales Service and Guarantee
Warranty: 12 Months or 1200 Hours
Type: Self-Starting Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
WT-R165
Output Type
AC Three Phase
Speed
Speed
Conditions of Use
Land Use
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
AC Rotating Exciter
Genset Output
400/230V 380/220V 440/220V 415/240V 480/277V
Phase
Single or Three Phase
Frequency
50Hz/60Hz
Engine Speed
1500rpm/1800rpm
IP
23
Battery Volatge
12V/24V
Aspiration Engine Typ
Turbocharged
Cooling System
Water Cooled
Governing Type
Electrical Starting GAC
Compress Ratio
17.0:1
Voltage Regulaor
AVR Auto Voltage Regulator
Alternator
Brushless, Self Exciting, 100% Copper
Insulation Class
Class “H”
Auto Transfter Switch
Optional ATS
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Including Wooden Package
Specification
2300x980x1500MM
Trademark
WINTPOWER
Origin
China
HS Code
85021200
Production Capacity
8000

Product Description

Weichai Kofo Ricardo Diesel Engine Power Generator Set Dg Genset 165kVA R6105bzlds Soundproof Silent Type 400/230V 380/220V 208/110V 440V 480V 600V 50Hz 60HzQuick DetailsRicardo diesel generator, Ricardo Generating set, Ricardo Genset, 20kva Ricardo generator, 25kva Ricardo generator, 30kva Ricardo generator, 40kva Ricardo generator, 50kva Ricardo generator, 100kw Ricardo generator, Ricardo power generator, Ricardo generator parts, Open type Ricardo generator, Silent Ricardo generator, Ricardo power station, KOFO diesel generator, Kofo genset, Low price Genset, Cheap diesel generatorChina brand kofo generator, generator price list China

WT-RRICARDO KOFOSERIESSPECIFICATION50HZ@1500RPM
GensetModel 50HZPF=0.8400/230V3Phase4Wire EngineModel cyl Bore Storke displacement Governor SilentTypeDimension
StandbyPower PrimePower Fuel consumption rate(g/kW.h)
MM MM L L×W×H(MM) WeightKG
KVA/KW KVA/KW
WT-R17 17/13 15/12 ≤247 4YT23-20D 4 85 90 2.04 Mechinical 2000*950*1450 680
WT-R22 22/18 20/16 ≤235 N4100DS-30 4 105 125 4.33 Mechinical 2300*980*1450 880
WT-R27 27/22 25/20 ≤235 N4100DS-30 4 105 125 4.33 Mechinical 2300*980*1450 880
WT-R33 33/26 30/24 ≤235 N4100DS-30 4 105 125 4.33 Mechinical 2300*980*1450 880
WT-R44 44/35 40/32 ≤230 N4105DS-38 4 105 125 4.33 Mechinical 2300*980*1450 880
WT-R50 50/40 45/36 ≤230 N4105DS-42 4 105 125 4.33 Mechinical 2300*980*1450 880
WT-R55 55/44 50/40 ≤225 N4105ZDS 4 105 125 4.33 Mechinical 2300*980*1450 950
WT-R66 66/53 60/48 ≤225 N4105ZDS 4 105 125 4.33 Mechinical 2300*980*1450 950
WT-R75 75/60 68/54 ≤225 N4105ZLDS 4 105 125 4.33 Mechinical 2300*980*1450 950
WT-R83 83/66 75/60 ≤225 R4105BZLDS 4 105 135 4.67 Mechinical 2300*980*1450 950
WT-R100 100/80 90/72 ≤218 R6105ZDS 6 105 125 6.49 Mechinical 2500*980*1450 1050
WT-R100 100/80 90/72 ≤218 4RT55-88D 4 105 125 6.49 Mechinical 2500*980*1450 1050
WT-R110 110/88 100/80 ≤218 R6105ZLDS 6 105 125 6.49 Mechinical 2500*980*1450 1050
WT-R110 110/88 100/80 ≤215 4RT55-110D 4 105 125 6.75 Mechinical 2500*980*1450 1050
WT-R120 120/96 110/88 ≤215 4RT55-110D 4 105 125 6.75 Mechinical 2500*980*1450 1050
WT-R138 138/110 125/100 ≤215 R6105AZLDS 6 105 135 7.01 Mechinical 2900*1100*1550 1250
WT-R165 165/132 150/120 ≤215 R6105BZLDS 6 108 135 7.41 Mechinical 2900*1100*1550 1250
WT-R206 206/165 187/150 ≤215 R6110ZLDS 6 110 135 7.69 Mechinical 2900*1100*1550 1250
WT-R220 220/176 200/160 ≤215 6126-42DE 6 136 130 9.73 Mechinical 3500*1300*1900 1850
WT-R250 250/200 225/180 ≤215 6126-42DE 6 136 130 9.73 Mechinical 3500*1300*1900 1850
WT-R275 275/220 250/200 ≤215 6126-42DE 6 136 130 9.73 Mechinical 3500*1300*1900 1850
WT-R300 300/240 275/220 ≤206 6126A-260DE 6 126 135 10.09 Mechinical 3500*1300*1900 1850
WT-R344 344/275 313/250 ≤206 WT12D-308E 6 126 160 11.97 Mechinical 3500*1300*1900 1950
WT-R413 413/330 375/300 ≤206 WT13-330DE 6 131 160 12.94 Mechinical 4200*1450*1850 1950
WT-R440 440/352 400/320 ≤206 WT13-360DE 6 131 160 12.94 Mechinical 4200*1450*1850 1950
WT-R500 500/400 450/360 ≤206 WT13A-390DE 6 131 165 13.4 Mechinical 4500*1600*2200 2050
WT-RRICARDO KOFOSERIESSPECIFICATION60HZ@1800RPM
GensetModel 60HZ PF=0.8 440/220V 3Phase 4Wire EngineModel cyl Bore Storke displacement Governor SilentTypeDimension
StandbyPower PrimePower Fuel consumption rate(g/kW.h)
MM MM L L×W×H(MM) WeightKG
KVA/KW KVA/KW
WT-R18 18/14 16/13 ≤247 4YT23-20D 4 85 90 2.04 Mechinical 2000*950*1450 680
WT-R25 25/20 23/18 ≤235 N4100DS-30 4 105 125 4.33 Mechinical 2300*980*1450 880
WT-R31 31/24 28/22 ≤235 N4100DS-30 4 105 125 4.33 Mechinical 2300*980*1450 880
WT-R37 37/30 33/27 ≤235 N4100DS-30 4 105 125 4.33 Mechinical 2300*980*1450 880
WT-R47 47/37 43/34 ≤230 N4105DS-38 4 105 125 4.33 Mechinical 2300*980*1450 880
WT-R55 55/44 50/40 ≤230 N4105DS-46 4 105 125 4.33 Mechinical 2300*980*1450 950
WT-R69 69/55 63/50 ≤230 N4105ZDS 4 105 125 4.33 Mechinical 2300*980*1450 950
WT-R83 83/66 75/60 ≤230 N4105ZLDS 4 105 125 4.33 Mechinical 2300*980*1450 950
WT-R91 91/73 83/66 ≤218 R4105BZLDS 4 105 135 4.67 Mechinical 2300*980*1450 950
WT-R106 106/85 96/77 ≤218 R6105ZDS 6 105 125 6.49 Mechinical 2500*980*1450 1050
WT-R124 124/99 113/90 ≤215 R6105ZLDS 6 105 135 7.01 Mechinical 2900*1100*1550 1250
WT-R151 151/121 138/110 ≤215 R6105AZLDS 6 105 135 7.01 Mechinical 2900*1100*1550 1250
WT-R179 179/143 163/130 ≤215 R6105BZLDS 6 108 135 7.41 Mechinical 2900*1100*1550 1250
WT-R222 220/176 200/160 ≤215 R6110ZLDS 6 110 135 7.69 Mechinical 2900*1100*1550 1250
WT-R242 242/194 220/176 ≤215 6126-68D 6 136 130 9.73 Mechinical 3500*1300*1900 1850
WT-R275 275/220 250/200 ≤215 6126-42D 6 136 130 9.73 Mechinical 3500*1300*1900 1850
WT-R303 303/242 275/220 ≤206 6126-42D 6 136 130 9.73 Mechinical 3500*1300*1900 1850
WT-R330 330/262 300/240 ≤206 6126A-260DE 6 126 160 11.97 Mechinical 3500*1300*1900 1950
WT-R385 385/308 350/280 ≤206 WT12D-308E 6 126 160 11.97 Mechinical 3500*1300*1900 1950

A.STANDARD SUPPLY:1.Brand new CCEC/DCEC, MITSUBISHI, DEUTZ, DOOSAN, YUCHAI, KUBOTA, RICARDO, YANGDONG,water cooled diesel engine.2.Brand newSTAMFORD, LEROY SOMER or WINTsingle bearing 3 phase brushless alternator with 100% copper, IP23 and H insulation class.3. Standard 50ºC radiator with safety guard, engine driven fan mounted on skid4. DEEPSEA, COMAP, SMARTGEN controller brand with Auto/Manual start and AMF function5. DELIXI, CHINT or ABBbranded MCCB circuit breaker mounted.6. Heavy-duty fabricated steel based frame with convenient lifting, forklift pockets7. Complete set mounted on a based frame with anti-vibration mountings.8. Industrial 9 dB muffler exhaust system with blexible connects and bellows.9. Based frame with fuel, oil and coolant drain cocks for easy maintenance.10. 12/24V DC electric start system with free maintaining battery & floating battery charger.11. Standard with built-in fuel tank for 8 hours running. Canopy noise levels @7 meters with 70 dB12. Test report of generator, set of drawings and manuals. CE, ISO9001 approvedΔ OPTIONAL SUPPLY: 1.Weatherproof canopy / Soundproof canopy / Trailer-mounted2.Engine / Alternator Pre-heaters3.Auto load sharing & synchronizing panel4.Build-in ATS (Auto start & stop Main Failure (AMF)5.Large 12/24 hours fuel tank6.Power output socketsΔTESTING ITEMSWintpower factory inspection: the test items before delivery are mainly as follows:1.Parts faults testing2.Fuel tank pressure testing3.Bolt tightening torque testing4.Painting thickness testing5.Voltage bearing and insulation testing6.The noise level is tested by requested7.loadingtest range 25% 50% 75% 100% 110% 75% 50% 25% 0%ΔWintpower Silent typeDiesel Generator, advantagesas follows:1. Integrated interface with humanized and practicablydesign2. Super silentmaterial and treatment reach 70dBA@1M full load3. Steel material thickness2MM to 4MM,cut and fold by CNC4. New safe door handle, updated lock, bottom forkliftand top lift5. Aviation outtake connectorad operation LED light6. Free maintenance battery with floating charger8. 8-24hoursbase fuel tank with electrical fuel indicator9. Powder coating canopies afterchemistry treatmentWeichai Kofo Ricardo Diesel Engine Power Generator Set Dg Genset 165kVA R6105bzlds Soundproof Silent Type 400/230V 380/220V 208/110V 440V 480V 600V 50Hz 60HzWeichai Kofo Ricardo Diesel Engine Power Generator Set Dg Genset 165kVA R6105bzlds Soundproof Silent Type 400/230V 380/220V 208/110V 440V 480V 600V 50Hz 60HzWeichai Kofo Ricardo Diesel Engine Power Generator Set Dg Genset 165kVA R6105bzlds Soundproof Silent Type 400/230V 380/220V 208/110V 440V 480V 600V 50Hz 60HzWeichai Kofo Ricardo Diesel Engine Power Generator Set Dg Genset 165kVA R6105bzlds Soundproof Silent Type 400/230V 380/220V 208/110V 440V 480V 600V 50Hz 60HzWeichai Kofo Ricardo Diesel Engine Power Generator Set Dg Genset 165kVA R6105bzlds Soundproof Silent Type 400/230V 380/220V 208/110V 440V 480V 600V 50Hz 60HzWeichai Kofo Ricardo Diesel Engine Power Generator Set Dg Genset 165kVA R6105bzlds Soundproof Silent Type 400/230V 380/220V 208/110V 440V 480V 600V 50Hz 60HzWeichai Kofo Ricardo Diesel Engine Power Generator Set Dg Genset 165kVA R6105bzlds Soundproof Silent Type 400/230V 380/220V 208/110V 440V 480V 600V 50Hz 60HzWeichai Kofo Ricardo Diesel Engine Power Generator Set Dg Genset 165kVA R6105bzlds Soundproof Silent Type 400/230V 380/220V 208/110V 440V 480V 600V 50Hz 60HzWeichai Kofo Ricardo Diesel Engine Power Generator Set Dg Genset 165kVA R6105bzlds Soundproof Silent Type 400/230V 380/220V 208/110V 440V 480V 600V 50Hz 60HzWeichai Kofo Ricardo Diesel Engine Power Generator Set Dg Genset 165kVA R6105bzlds Soundproof Silent Type 400/230V 380/220V 208/110V 440V 480V 600V 50Hz 60HzWeichai Kofo Ricardo Diesel Engine Power Generator Set Dg Genset 165kVA R6105bzlds Soundproof Silent Type 400/230V 380/220V 208/110V 440V 480V 600V 50Hz 60HzΔFAQWhat’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .ΔWINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useΔWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
