WT Trailer type Generator Mobile Type Generator Car Power Generation
WT Trailer type Generator Mobile Type Generator Car Power Generation
| Dimension(mm) | L：12500 W：2500 H：1650 | ||
| Emission | Axles | 1 | |
| Max speed(km/h) | Weight(kg) | 15000 | |
| Playload mass | Rated load(kg) | 32000 | |
| Steer type | Curb weight(kg) | 3000 | |
| Wheel base(mm)： | 8950 | Tire size | 9.00R20 |
| No. of Steel leaf spring ( front: back) | -/4,-/7,-/8,-/10,-/12,-/13 | Saddle max load(kg) | 5000 |
| Wheel tread(front/back)mm | Front :back-1840 | Tires | 4 |
| Reflecting manufacture | 3MChina Limit co,. ltd | Reflecting marking | 983D,TM1200-1,DMCT1000 |
| Reflecting marking logo | 3M,DM | anti-lock brake system | included |
| vehicle identification number(VIN) | LA991RJ1×××LKB××× | Front/Back overhang | -/2500 |
| Note | Traction site height is 90mm, used for a 40HQ container, including rear molding, reinforcing rib in middle part, wheel cowling, the optional parts cause weight change within 3%. ABS model HNABS4S/4M. Side protective device made up with 235board. Rear flank device made with electro welding connecting, section size of rear flank device is140mmx55mmx520mm. | ||
| WT Trailer type Generator SERIES SPECIFICATION | |||||||
| NO | Model | Trailer Main Spefication | Generator Power KW | Generator Weight KG | Trailer Dimension mm | Loading Surface Dimension MM |   |
| 1 | WT-T1000 | Single axle with two wheels, front supporting guide wheel, height adjustable traction mechanism, leaf spring (optional torsion bar bridge), supporting leg, brake system (traveling inertia brake, decoupling emergency brake, parking hand brake), tail light Electrical assembly | 20 | 1000 | 3100*1750*910 | 2600*1100*705 | |
| 2 | WT-T1050 | 30 | 1050 | 3100*1750*910 | 2600*1100*705 | ||
| 3 | WT-T1100 | 45 | 1100 | 3100*1750*910 | 2600*1100*705 | ||
| 4 | WT-T1650 | 68 | 1650 | 4700*1750*950 | 3200*1100*705 | ||
| 5 | WT-T1680 | 77 | 1680 | 4700*1750*950 | 3200*1100*705 | ||
| 6 | WT-T1700 | 91 | 1700 | 4700*1750*950 | 3200*1100*705 | ||
| 7 | WT-T2200 | Two-axle four-wheel, front supporting guide wheel, height adjustable Traction mechanism, leaf spring (optional torsion bar bridge) , Braking system (driving inertial braking, emergency decoupling Brake, parking hand brake), taillight electrical assembly |
104 | 2200 | 4700*1750*1000 | 3200*1100*730 |  |
| 10 | WT-T2580 | 140 | 2580 | 4900*1750*1000 | 3400*1100*730 | ||
| 13 | WT-T3300 | 160 | 3300 | 4900*1860*950 | 3400*1200*705 | ||
| 14 | WT-T3650 | Two-axle four-wheel, traction mechanism, steering knuckle, leaf spring (optional torsion bar bridge), support leg, brake system (travel air brake, decoupling emergency brake , Parking hand brake), taillight electrical assembly |
200 | 3650 | 5500*1960*1000 | 4000*1300*730 |  |
| 15 | WT-T4150 | 250 | 4150 | 5500*2400*1100 | 4200*1460*800 | ||
| 16 | WT-T4250 | 275 | 4250 | 5500*2400*1100 | 4200*1460*800 | ||
| 17 | WT-T4370 | 300 | 4370 | 5500*2400*1100 | 4200*1460*800 | ||
