FAW Diesel Power Generator Set Dg Genset 16kVA 22kVA 28kVA 32kVA 34kVA 44kVA 60kVA

FAW Diesel Power Generator Set Dg Genset 16kVA 22kVA 28kVA 32kVA 34kVA 44kVA 60kVA

Quick Details:

After-sales Service: After Sales Service and Guarantee
Warranty: 12 Months or 1200 Hours
Type: Self-Starting Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
WT-FA60
Output Type
AC Three Phase
Speed
Speed
Conditions of Use
Land Use
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
AC Rotating Exciter
Genset Output
400/230V 380/220V 440/220V 415/240V 480/277
Phase
Single or Three Phase
Frequency
50Hz/60Hz
Engine Speed
1500rpm/1800rpm
Battery Volatge
12V/24V
Aspiration Engine Type
Turbocharged
Cooling System
Water Cooled
Governing Type
Electrical Starting GAC
Compress Ratio
17.0:1
Voltage Regulaor
AVR Auto Voltage Regulator
Voltage Regulation Maintanined
Within 0.5%
Alternator
Brushless, Self Exciting, 100% Copper
Insulation Class
Class “H”
Auto Transfter Switch
Optional ATS
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Including Wooden Package
Specification
2300x980x1500MM
Trademark
WINTPOWER
Origin
China
HS Code
85021200
Production Capacity
8000

Product Description

FAW Diesel Power Generator Set Dg Genset 16kVA 4dw81-23D 22kVA 4dw91-29d 28kVA 4dw92-35D 32kVA 4dw92-39d 34kVA 4dx21-45D 44kVA 4dx21-53D 60kVA 4dx22-65DQuick DetailsFAW diesel generator, FAW Generating set, FAW Genset, 40kva FAW generator, 50kva FAW generator, 80kva FAW generator, 100kva FAW generator, 150kva FAW generator, 200kw FAW generator, 400kva FAW power generator, FAW generator parts, Open type FAW generator, Silent FAW generator, FAW power station, Weichai diesel generator, Low price Genset, Cheap diesel generatorChina brand generator, generator price list China

WT-FA FAW SERIES SPECIFICATION 50HZ @ 1500RPM
Genset Model 50HZ PF=0.8 400/230V 3Phase 4Wire Engine Model Stamford Alternator Leroy Somer Alternator Wintpower Alternator
Prime Power Standby Power
KW/KVA KW/KVA
WT-FA16 1215 13/16 4DW81-23D PI 044G TAL-A40-D WT164G12.8
WT-FA22 16/20 18/22 4DW91-29D PI 144D TAL-A40-F WT184G18
WT-FA28 20/25 22/28 4DW92-35D PI 144E TAL-A40-G WT184G22
WT-FA32 24/30 26/32 4DW92-39D PI 144G TAL-A42-C WT184G25
WT-FA34 25/31 28/34 4DX21-45D PI 144H TAL-A42-E WT184G25
WT-FA44 32/40 35/44 4DX21-53D PI 144J TAL-A42-F WT184G30
WT-FA60 40/50 44/55 4DX22-65D UCI 224D TAL-A42-G WT224G40
WT-FA66 48/60 53/66 4DX23-78D UCI224E TAL-A42-H WT224G45
WT-FA75 54/68 60/75 4110/125Z-09D UCI 224F TAL-A44-C WT224G58
WT-FA100 72/98 80/100 CA4DF2-12D UCI 274C TAL-A44-D WT274G80
WT-FA110 85/106 88/110 CA6DF2D-14D UCI 274C TAL-A44-D WT274G80
WT-FA138 100/125 110/138 CA6DF2-17D UCI 274E TAL-A44-E WT274G112
WT-FA165 120/150 132/165 CA6DF2-19D UCI 274F TAL-A44-J WT274G128
WT-FA206 150/187 165/206 CA6DL1-24D UCI 274G TAL-A44-M WT274G160
WT-FA250 180/225 200/250 CA6DL2-27D UCD 274J TAL-A46-C WT274G180
WT-FA275 200/250 220/275 CA6DL2-30D UCD 274K TAL-A46-D WT274G200
WT-FA338 250/312 270/338 CA6DM2J-39D HCI 444ES TAL-A46-G WT314G250
WT-FA350 270/325 280/350 CA6DM2J-41D HCI 444E TAL-A46-H WT314G280
WT-FA400 300/375 320/400 CA6DN1J-45D HCI 444FS TAL-A47-A WT314G300
WT-FA FAW SERIES SPECIFICATION 60HZ @ 1800RPM
Genset Model 60HZ PF=0.8 440/220V 3Phase 4Wire Engine Model Stamford Alternator Leroy Somer Alternator Wintpower Alternator
Prime Power Standby Power
KW/KVA KW/KVA
WT-FA20 15/19 16/20 4DW81-28D PI 044H TAL-A40-E WT164G12.8
WT-FA25 18/22 20/25 4DW91-38D PI 144D TAL-A40-G WT184G18
WT-FA30 22/28 24/30 4DW91-38D PI 144E TAL-A40-G WT184G18
WT-FA35 25/31 28/35 4DW92-42D PI 144F TAL-A42-C WT184G22
WT-FA40 30/38 32/40 4DW93-50D PI 144H TAL-A42-E WT184G25
WT-FA40 30/38 32/40 4DX21-53D PI 144H TAL-A42-E WT184G25
WT-FA50 36/45 40/50 4DX21-61D PI 144J TAL-A42-F WT184G30
WT-FA66 48/60 53/66 4DX23-82D UCI 224D TAL-A42-H WT224G40
WT-FA90 65/81 72/90 4110/125Z-11D UCI 224F TAL-A44-C WT224G58
WT-FA117 85/106 94/117 CA4DF2-14D UCI274C TAL-A44-D WT274G80
WT-FA125 95/112 100/125 CA6DF2D-16D UCI 274C TAL-A44-E WT274G80
WT-FA150 110/137 120/150 CA6DF2-18D UCI 274D TAL-A44-H WT274G90
WT-FA165 130/150 132/165 CA6DF2-21D UCI 274E TAL-A44-J WT274G112
WT-FA220 160/200 176/220 CA6DL1-27D UCI 274G TAL-A46-L WT274G140
WT-FA275 200/250 220/275 CA6DL2-32D UCI 274J TAL-A46-C WT274G180
WT-FA350 270/325 280/350 CA6DM2J-42D HCI 444D TAL-A46-F WT314G240
WT-FA440 320/400 352/440 CA6DM3J-49D HCI 444E TAL-A46-H WT314G280

A.STANDARD SUPPLY:1.Brand new CCEC/DCEC, DEUTZ, DOOSAN, YUCHAI, KUBOTA, RICARDO, YANGDONG, water cooled diesel engine.2.Brand newSTAMFORD, LEROY SOMER or WINTsingle bearing 3 phase brushless alternator with 100% copper, IP23 and H insulation class.3. Standard 50ºC radiator with safety guard, engine driven fan mounted on skid4. DEEPSEA, COMAP, SMARTGEN controller brand with Auto/Manual start and AMF function5. DELIXI, CHINT or ABBbranded MCCB circuit breaker mounted.6. Heavy-duty fabricated steel based frame with convenient lifting, forklift pockets7. Complete set mounted on a based frame with anti-vibration mountings.8. Industrial 9 dB muffler exhaust system with blexible connects and bellows.9. Based frame with fuel, oil and coolant drain cocks for easy maintenance.10. 12/24V DC electric start system with free maintaining battery & floating battery charger.11. Standard with built-in fuel tank for 8 hours running. Canopy noise levels @7 meters with 70 dB12. Test report of generator, set of drawings and manuals. CE, ISO9001 approvedΔ OPTIONAL SUPPLY: 1.Weatherproof canopy / Soundproof canopy / Trailer-mounted2.Engine / Alternator Pre-heaters3.Auto load sharing & synchronizing panel4.Build-in ATS (Auto start & stop Main Failure (AMF)5.Large 12/24 hours fuel tank6.Power output socketsΔTESTING ITEMSWintpower factory inspection: the test items before delivery are mainly as follows:1.Parts faults testing2.Fuel tank pressure testing3.Bolt tightening torque testing4.Painting thickness testing5.Voltage bearing and insulation testing6.The noise level is tested by requested7.loadingtest range 25% 50% 75% 100% 110% 75% 50% 25% 0%ΔWintpower Silent typeDiesel Generator, advantagesas follows:1. Integrated interface with humanized and practicablydesign2. Super silentmaterial and treatment reach 70dBA@1M full load3. Steel material thickness2MM to 4MM,cut and fold by CNC4. New safe door handle, updated lock, bottom forkliftand top lift5. Aviation outtake connectorad operation LED light6. Free maintenance battery with floating charger8. 8-24hoursbase fuel tank with electrical fuel indicator9. Powder coating canopies afterchemistry treatmentFAW Diesel Power Generator Set Dg Genset 16kVA 4dw81-23D 22kVA 4dw91-29d 28kVA 4dw92-35D 32kVA 4dw92-39d 34kVA 4dx21-45D 44kVA 4dx21-53D 60kVA 4dx22-65DFAW Diesel Power Generator Set Dg Genset 16kVA 4dw81-23D 22kVA 4dw91-29d 28kVA 4dw92-35D 32kVA 4dw92-39d 34kVA 4dx21-45D 44kVA 4dx21-53D 60kVA 4dx22-65DFAW Diesel Power Generator Set Dg Genset 16kVA 4dw81-23D 22kVA 4dw91-29d 28kVA 4dw92-35D 32kVA 4dw92-39d 34kVA 4dx21-45D 44kVA 4dx21-53D 60kVA 4dx22-65DFAW Diesel Power Generator Set Dg Genset 16kVA 4dw81-23D 22kVA 4dw91-29d 28kVA 4dw92-35D 32kVA 4dw92-39d 34kVA 4dx21-45D 44kVA 4dx21-53D 60kVA 4dx22-65DFAW Diesel Power Generator Set Dg Genset 16kVA 4dw81-23D 22kVA 4dw91-29d 28kVA 4dw92-35D 32kVA 4dw92-39d 34kVA 4dx21-45D 44kVA 4dx21-53D 60kVA 4dx22-65DFAW Diesel Power Generator Set Dg Genset 16kVA 4dw81-23D 22kVA 4dw91-29d 28kVA 4dw92-35D 32kVA 4dw92-39d 34kVA 4dx21-45D 44kVA 4dx21-53D 60kVA 4dx22-65DFAW Diesel Power Generator Set Dg Genset 16kVA 4dw81-23D 22kVA 4dw91-29d 28kVA 4dw92-35D 32kVA 4dw92-39d 34kVA 4dx21-45D 44kVA 4dx21-53D 60kVA 4dx22-65DFAW Diesel Power Generator Set Dg Genset 16kVA 4dw81-23D 22kVA 4dw91-29d 28kVA 4dw92-35D 32kVA 4dw92-39d 34kVA 4dx21-45D 44kVA 4dx21-53D 60kVA 4dx22-65DFAW Diesel Power Generator Set Dg Genset 16kVA 4dw81-23D 22kVA 4dw91-29d 28kVA 4dw92-35D 32kVA 4dw92-39d 34kVA 4dx21-45D 44kVA 4dx21-53D 60kVA 4dx22-65DFAW Diesel Power Generator Set Dg Genset 16kVA 4dw81-23D 22kVA 4dw91-29d 28kVA 4dw92-35D 32kVA 4dw92-39d 34kVA 4dx21-45D 44kVA 4dx21-53D 60kVA 4dx22-65DΔFAQWhat’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .ΔWINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useΔWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
