Mtu Diesel Power Generator Set Dg Genset 863kVA 1000kVA 1100kVA 1250kVA 1375kVA

Mtu Diesel Power Generator Set Dg Genset 863kVA 1000kVA 1100kVA 1250kVA 1375kVA

Quick Details:

After-sales Service: After Sales Service and Guarantee
Warranty: 12 Months or 1200 Hours
Type: Self-Starting Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
WT-MT1375
Output Type
AC Three Phase
Speed
Speed
Conditions of Use
Land Use
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
AC Rotating Exciter
Genset Output
400/230V, 380/220V, 440/220V, 415/240V, 480/277V
Phase
Single or Three Phase
Frequency
50Hz/60Hz
Engine Speed
1500rpm/1800rpm
Battery Volatge
12V/24V
Aspiration Engine Type
Turbocharged
Cooling System
Water Cooled
Governing Type
Electrical Starting GAC
Compress Ratio
17:1
Voltage Regulator
AVR Auto Voltage Regulator
Voltage Regulation Maintanined
Within 0.5%
Alternator
Brushless, Self Exciting, 100% Copper
Insulation Class
Class “H”
Auto Transfter Switch
Optional ATS
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Including Wooden Package
Specification
3500x1200x1800MM
Trademark
WINTPOWER
Origin
China
HS Code
85021310
Production Capacity
8000

Product Description

Mtu Diesel Power Generator Set Dg Genset 863kVA 12V2000g65 1000kVA 16V2000g25 1100kVA 16V2000g65 1250kVA 18V2000g65 1375kVA 12V4000g21r 1000kwQuick DetailsMTU diesel generator, MTU Generating set, MTU Genset, 500kva MTU generator,800kva MTU generator, 1000kva MTU generator, 1500kva MTU generator, 2000kvaMTU generator, 3000kva MTU generator, MTU power generator, MTU generator parts,Open type MTU generator, Silent MTU generator, MTU power station, Germany EngineGenset, Germany Power generator

WT-MT MTU ENGINES SPECIFICATION 50HZ @ 1500RPM
Genset Model 50HZ PF=0.8 400/230V 3Phase 4Wire Engine Model cyl displacement Battery Vol. Max power Governor Open Type Dimension
Standby Power Prime Power Cons 100%(L/H)
KVA/KW KVA/KW L V KW L×W×H(MM) Weight KG
WT-MT300 300/240 275/220 66 6R1600G70F 6L 10.5 24 274 ECM 3159*1195*1897 2760
WT-MT330 330/264 300/240 72 6R1600G80F 6L 10.5 24 301 ECM 3159*1195*1897 2800
WT-MT388 388/310 350/280 84 8V1600G70F 8V 14 24 358 ECM 2990*1325*2020 3250
WT-MT440 440/352 400/320 90 8V1600G80F 8V 14 24 394 ECM 2990*1325*2020 3270
WT-MT500 500/400 450/360 109 10V1600G70F 10V 17.5 24 448 ECM 3250*1295*2058 3850
WT-MT550 550/440 500/400 120 10V1600G80F 10V 17.5 24 493 ECM 3250*1295*2058 3850
WT-MT650 650/520 590/472 132 12V1600G70F 12V 21 24 576 ECM 3468*1498*2158 4500
WT-MT688 688/550 625/500 140 12V2000G25 12V 23.88 24 580 ECM 4125*1470*2130 5350
WT-MT715 715/572 650/520 147 12V1600G80F 12V 21 24 634 ECM 3468*1498*2158 4600
WT-MT725 725/580 659/527 140 12V2000G25 12V 23.88 24 580 ECM 4125*1470*2130 5350
WT-MT863 863/690 785/628 167 12V2000G65 12V 23.88 24 695 ECM 4125*1470*2130 6100
WT-MT1000 1000/800 910/728 190 16V2000G25 16V 31.84 24 810 ECM 4468*1470*2230 7000
WT-MT1100 1100/880 1000/800 209 16V2000G65 16V 31.84 24 890 ECM 4468*1470*2230 7150
WT-MT1250 1250/1000 1125/900 240 18V2000G65 18V 35.82 24 1000 ECM 4719*1912*2430 8000
WT-MT1375 1375/1100 1250/1000 280 12V4000G21R 12V 48.7 24 1212 ECM 6326*2200*2523 14000
WT-MT1500 1500/1200 1375/1100 280 12V4000G23R 12V 57.2 24 1325 ECM 6326*2200*2523 14000
WT-MT1650 1650/1320 1500/1200 316 12V4000G23 12V 57.2 24 1420 ECM 6326*2200*2523 14600
WT-MT1800 1800/1440 1640/1312 316 12V4000G23 12V 57.2 24 1420 ECM 6326*2200*2523 14600
WT-MT2000 2000/1600 1820/1456 358 12V4000G63 12V 57.2 24 1575 ECM 6326*2200*2523 15200
WT-MT2090 2090/1672 1900/1520 406 16V4000G23 16V 76.3 24 1798 ECM 6646*2200*2622 17800
WT-MT2280 2280/1824 2075/1660 406 16V4000G23 16V 76.3 24 1798 ECM 6766*2200*2622 17800
WT-MT2420 2420/1936 2200/1760 505 16V4000G63 16V 76.3 24 1965 ECM 6930*2200*2622 17800
WT-MT2500 2500/2000 2250/1800 505 16V4000G63 16V 76.3 24 1965 ECM 7000*2200*2622 17800
WT-MT2750 2750/2200 2500/2000 550 20V4000G23 20V 95.4 24 2200 ECM 7460*2555*2773 24000
WT-MT3000 3000/2400 2750/2200 550 20V4000G63 20V 95.4 24 2420 ECM 7930*2555*2773 24900
WT-MT3300 3300/2640 3000/2400 590 20V4000G63L 20V 95.4 24 2590 ECM 7930*2555*2773 26800
WT-MT MTU SERIES SPECIFICATION 60HZ @ 1800RPM
Genset Model 60HZ PF=0.8 440/220V 3Phase 4Wire Engine specification Genset canopy data Genset open data
Standby Power Prime Power Cons 100%(L/H) Engine Model Cyl. Gov. Displacement(L) Dimention(MM) weight(KG) Dimention(MM) Weight(KG)
KVA/KW KVA/KW
WT-MT340 340/272 310/248 58.6 6R1600G70S 6L ECM 10.5 4350*1500*2260 4870 3000*1450*1815 2760
WT-MT375 375/300 340/272 63.4 6R1600G80S 6L ECM 10.50 4350*1500*2260 4870 3000*1450*1815 2800
WT-MT450 450/360 410/328 74 8V1600G70S 8V ECM 14 4350*1600*2500 5270 2840*1660*1975 3250
WT-MT490 490/392 445/356 80 8V1600G80S 8V ECM 14.00 4350*1600*2500 5270 2840*1660*1975 3270
WT-MT565 565/452 513/410 91 10V1600G70S 10V ECM 17.5 4650*1600*2500 5270 3230*1660*2045 3850
WT-MT625 625/500 570/456 102 10V1600G80S 10V ECM 17.50 4650*1600*2500 5270 3230*1660*2045 3850
WT-MT688 688/550 625/500 113 12V1600G70S 12V ECM 21 4950*2000*2514 5930 3400*1660*2145 4500
WT-MT750 750/600 685/550 123 12V1600G80S 12V ECM 21.00 4950*2000*2514 5930 3665*1660*2145 5350
WT-MT875 875/700 795/636 152.6 12V2000G45 12V ECM 23.88 20GP container 10250 4050*1585*2150 5350
WT-MT980 980/784 890/712 170 12V2000G85 12V ECM 23.88 20GP container 10250 4050*1585*2150 6100
WT-MT1130 1130/904 1025/820 195.9 16V2000G45 16V ECM 31.84 20GP container 10250 4475*1650*2300 7000
WT-MT1250 1250/1000 1138/910 212.5 16V2000G85 16V ECM 31.84 20GP container 12160 4475*1650*2300 7150
WT-MT1463 1463/1170 1338/1070 254 18V2000G85 18V ECM 35.82 20GP container 12110 4700*1900*2500 8000
WT-MT1650 1650/1320 1500/1200 282 12V4000G43 12V ECM 57.20 40HQ container 20800 6350*2250*2500 14600
WT-MT1900 1900/1520 1713/1370 315 12V4000G43 12V ECM 57.2 40HQ container 20800 6350*2250*2500 14600
WT-MT2070 2070/1656 1935/1548 344 12V4000G83 12V ECM 57.20 40HQ container 20800 6350*2250*2500 14600
WT-MT2200 2200/1760 2000/1600 356 12V4000G83 12V ECM 57.2 40HQ container 20800 6350*2250*2500 15200
WT-MT2425 2425/1940 2200/1760 398 16V4000G43 16V ECM 76.30 40HQ container 21400 6870*2740*2650 17800
WT-MT2500 2500/2000 2300/1840 415 16V4000G43 16V ECM 76.3 40HQ container 21400 6870*2740*2650 17800
WT-MT2750 2750/2200 2500/2000 449 16V4000G83 16V ECM 76.30 40HQ container 21400 6870*2740*2650 17800
WT-MT3100 3100/2480 2825/2260 518 20V4000G43 20V ECM 95.4 40HQ container 21400 6870*2740*2650 17800
WT-MT3438 3438/2750 3125/2500 568 20V4000G83 20V ECM 95.40 40HQ container 21400 7650*2990*2690 24000
WT-MT3750 3750/3000 3438/2750 622 20V4000G83L 20V ECM 95.4 40HQ container 21400 7650*2990*2690 24900
WT-MT4000 4000/3200 3636/2900 663 20V4000G83L 20V ECM 95.40 40HQ container 21400 7800*2990*2800 26800

A.STANDARD SUPPLY:1.Brand new CCEC/DCEC, DEUTZ, DOOSAN, YUCHAI, KUBOTA, RICARDO, YANGDONG,water cooled diesel engine.2.Brand newSTAMFORD, LEROY SOMER or WINTsingle bearing 3 phase brushless alternator with 100% copper, IP23 and H insulation class.3. Standard 50ºC radiator with safety guard, engine driven fan mounted on skid4. DEEPSEA, COMAP, SMARTGEN controller brand with Auto/Manual start and AMF function5. DELIXI, CHINT or ABBbranded MCCB circuit breaker mounted.6. Heavy-duty fabricated steel based frame with convenient lifting, forklift pockets7. Complete set mounted on a based frame with anti-vibration mountings.8. Industrial 9 dB muffler exhaust system with blexible connects and bellows.9. Based frame with fuel, oil and coolant drain cocks for easy maintenance.10. 12/24V DC electric start system with free maintaining battery & floating battery charger.11. Standard with built-in fuel tank for 8 hours running. Canopy noise levels @7 meters with 70 dB12. Test report of generator, set of drawings and manuals. CE, ISO9001 approvedΔ OPTIONAL SUPPLY: 1.Weatherproof canopy / Soundproof canopy / Trailer-mounted2.Engine / Alternator Pre-heaters3.Auto load sharing & synchronizing panel4.Build-in ATS (Auto start & stop Main Failure (AMF)5.Large 12/24 hours fuel tank6.Power output socketsΔTESTING ITEMSWintpower factory inspection: the test items before delivery are mainly as follows:1.Parts faults testing2.Fuel tank pressure testing3.Bolt tightening torque testing4.Painting thickness testing5.Voltage bearing and insulation testing6.The noise level is tested by requested7.loadingtest range 25% 50% 75% 100% 110% 75% 50% 25% 0%ΔWintpower Silent typeDiesel Generator, advantagesas follows:1. Integrated interface with humanized and practicablydesign2. Super silentmaterial and treatment reach 70dBA@1M full load3. Steel material thickness2MM to 4MM,cut and fold by CNC4. New safe door handle, updated lock, bottom forkliftand top lift5. Aviation outtake connectorad operation LED light6. Free maintenance battery with floating charger8. 8-24hoursbase fuel tank with electrical fuel indicator9. Powder coating canopies afterchemistry treatmentMtu Diesel Power Generator Set Dg Genset 863kVA 12V2000g65 1000kVA 16V2000g25 1100kVA 16V2000g65 1250kVA 18V2000g65 1375kVA 12V4000g21r 1000kwMtu Diesel Power Generator Set Dg Genset 863kVA 12V2000g65 1000kVA 16V2000g25 1100kVA 16V2000g65 1250kVA 18V2000g65 1375kVA 12V4000g21r 1000kwMtu Diesel Power Generator Set Dg Genset 863kVA 12V2000g65 1000kVA 16V2000g25 1100kVA 16V2000g65 1250kVA 18V2000g65 1375kVA 12V4000g21r 1000kwMtu Diesel Power Generator Set Dg Genset 863kVA 12V2000g65 1000kVA 16V2000g25 1100kVA 16V2000g65 1250kVA 18V2000g65 1375kVA 12V4000g21r 1000kwMtu Diesel Power Generator Set Dg Genset 863kVA 12V2000g65 1000kVA 16V2000g25 1100kVA 16V2000g65 1250kVA 18V2000g65 1375kVA 12V4000g21r 1000kwMtu Diesel Power Generator Set Dg Genset 863kVA 12V2000g65 1000kVA 16V2000g25 1100kVA 16V2000g65 1250kVA 18V2000g65 1375kVA 12V4000g21r 1000kwMtu Diesel Power Generator Set Dg Genset 863kVA 12V2000g65 1000kVA 16V2000g25 1100kVA 16V2000g65 1250kVA 18V2000g65 1375kVA 12V4000g21r 1000kwMtu Diesel Power Generator Set Dg Genset 863kVA 12V2000g65 1000kVA 16V2000g25 1100kVA 16V2000g65 1250kVA 18V2000g65 1375kVA 12V4000g21r 1000kwMtu Diesel Power Generator Set Dg Genset 863kVA 12V2000g65 1000kVA 16V2000g25 1100kVA 16V2000g65 1250kVA 18V2000g65 1375kVA 12V4000g21r 1000kwMtu Diesel Power Generator Set Dg Genset 863kVA 12V2000g65 1000kVA 16V2000g25 1100kVA 16V2000g65 1250kVA 18V2000g65 1375kVA 12V4000g21r 1000kwMtu Diesel Power Generator Set Dg Genset 863kVA 12V2000g65 1000kVA 16V2000g25 1100kVA 16V2000g65 1250kVA 18V2000g65 1375kVA 12V4000g21r 1000kwΔFAQWhat’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .ΔWINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useΔWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
