Diesel Power Generator Super Silent Low Noise Genset Rainproof Outdoor Residential Use

Diesel Power Generator Super Silent Low Noise Genset Rainproof Outdoor Residential Use

Quick Details:

After-sales Service: After Sales Service and Guarantee
Warranty: 12 Months or 1200 Hours
Type: Self-Starting Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
WT-C88
Output Type
AC Three Phase
Speed
Speed
Conditions of Use
Land Use
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
AC Rotating Exciter
Genset Output
400/230V, 380/220V, 440/220V, 415/240V, 480/277V
Phase
Single or Three Phase
Frequency
50Hz/60Hz
Engine Speed
1500rpm/1800rpm
Battery Volatge
12V/24V
Cooling System
Water Cooled
Alternator
Brushless, Self Exciting, 100% Copper
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Including Wooden Package
Specification
2900x980x1550MM
Trademark
WINTPOWER
Origin
China
HS Code
85021200
Production Capacity
8000

Product Description

Diesel Power Generator Super Silent Generator Low Noise Genset Rainproof Outdoor Generator Residential Use

WT SUPER SILENT GENERATOR SERIES SOUNDPROOF NOISE LEVEL TESTING
Genset Model 50HZ PF=0.8 400/230V 3Phase 4Wire Engine Model Standard Silent Canopy Super Silent Canopy
Standby Power Prime Power Cons 100%(L/H) Dimension(MM) Soundproof Level dBA@1M Dimension(MM) Soundproof Level dBA@1M
KVA/KW KVA/KW
WT-P10S 10/8 9/7.2 2.6 403D-11G 2000*800*1150 70 2250*900*1250 59
WT-P15S 15/12 13/10 3.7 403D-15G 2000*800*1150 70 2250*900*1250 59
WT-P22S 22/18 20/16 5.3 404D-22G 2000*800*1150 70 2250*900*1250 59
WT-P28S 27/22 25/20 7.1 404D-22TG 2000*800*1150 70 2250*900*1250 59
WT-P33S 33/26 30/24 7.1 1103A-33G 2250*900*1250 70 2600*980*1550 59
WT-P50S 50/40 45/36 10.7 1103A-33TG1 2250*900*1250 70 2600*980*1550 59
WT-P66S 66/53 60/48 13.9 1103A-33TG2 2250*900*1250 70 2600*980*1550 59
WT-P72S 72/57.6 65/52 14.8 1104A-44TG1 2250*900*1250 70 2600*980*1550 59
WT-P88S 88/70.4 80/64 18.7 1104C-44TAG1 2600*980*1550 75 2900*1080*1550 65
WT-P110S 110/88 100/80 22.6 1104C-44TAG2 2600*980*1550 75 2900*1080*1550 65
WT-P138S 138/110 125/100 29.9 1106A-70TG1 2900*1080*1550 75 3100*1100*1550 65
WT-P150S 150/120 135/108 29.9 1106A-70TG1 2900*1080*1550 75 3100*1100*1550 65
WT-P165S 165/132 150/120 45.8 1106A-70TAG2 2900*1080*1550 75 3100*1100*1550 65
WT-P200S 200/160 180/144 41.6 1106A-70TAG3 2900*1080*1550 75 3100*1100*1550 65
WT-P220S 220/176 200/160 45.8 1106A-70TAG4 2900*1080*1550 75 3100*1100*1550 65

Diesel Power Generator Super Silent Generator Low Noise Genset Rainproof Outdoor Generator Residential UseDiesel Power Generator Super Silent Generator Low Noise Genset Rainproof Outdoor Generator Residential UseDiesel Power Generator Super Silent Generator Low Noise Genset Rainproof Outdoor Generator Residential UseDiesel Power Generator Super Silent Generator Low Noise Genset Rainproof Outdoor Generator Residential UseDiesel Power Generator Super Silent Generator Low Noise Genset Rainproof Outdoor Generator Residential UseDiesel Power Generator Super Silent Generator Low Noise Genset Rainproof Outdoor Generator Residential UseDiesel Power Generator Super Silent Generator Low Noise Genset Rainproof Outdoor Generator Residential UseDiesel Power Generator Super Silent Generator Low Noise Genset Rainproof Outdoor Generator Residential UseDiesel Power Generator Super Silent Generator Low Noise Genset Rainproof Outdoor Generator Residential UseDiesel Power Generator Super Silent Generator Low Noise Genset Rainproof Outdoor Generator Residential UseDiesel Power Generator Super Silent Generator Low Noise Genset Rainproof Outdoor Generator Residential UseA.STANDARD SUPPLY:1.Brand new CCEC/DCEC, DEUTZ, DOOSAN, YUCHAI, KUBOTA, RICARDO, YANGDONG, water cooled diesel engine.2.Brand newSTAMFORD, LEROY SOMER or WINTsingle bearing 3 phase brushless alternator with 100% copper, IP23 and H insulation class.3. Standard 50ºC radiator with safety guard, engine driven fan mounted on skid4. DEEPSEA, COMAP, SMARTGEN controller brand with Auto/Manual start and AMF function5. DELIXI, CHINT or ABBbranded MCCB circuit breaker mounted.6. Heavy-duty fabricated steel based frame with convenient lifting, forklift pockets7. Complete set mounted on a based frame with anti-vibration mountings.8. Industrial 9 dB muffler exhaust system with blexible connects and bellows.9. Based frame with fuel, oil and coolant drain cocks for easy maintenance.10. 12/24V DC electric start system with free maintaining battery & floating battery charger.11. Standard with built-in fuel tank for 8 hours running. Canopy noise levels @7 meters with 70 dB12. Test report of generator, set of drawings and manuals. CE, ISO9001 approvedΔ OPTIONAL SUPPLY: 1.Weatherproof canopy / Soundproof canopy / Trailer-mounted2.Engine / Alternator Pre-heaters3.Auto load sharing & synchronizing panel4.Build-in ATS (Auto start & stop Main Failure (AMF)5.Large 12/24 hours fuel tank6.Power output socketsΔTESTING ITEMSWintpower factory inspection: the test items before delivery are mainly as follows:1.Parts faults testing2.Fuel tank pressure testing3.Bolt tightening torque testing4.Painting thickness testing5.Voltage bearing and insulation testing6.The noise level is tested by requested7.loadingtest range 25% 50% 75% 100% 110% 75% 50% 25% 0%ΔWintpower Silent typeDiesel Generator, advantagesas follows:1. Integrated interface with humanized and practicablydesign2. Super silentmaterial and treatment reach 70dBA@1M full load3. Steel material thickness2MM to 4MM,cut and fold by CNC4. New safe door handle, updated lock, bottom forkliftand top lift5. Aviation outtake connectorad operation LED light6. Free maintenance battery with floating charger8. 8-24hoursbase fuel tank with electrical fuel indicator9. Powder coating canopies afterchemistry treatmentΔFAQWhat’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .ΔWINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useΔWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
