Diesel Power Generator Lovol Genset China Brand Generating Silent Type

Diesel Power Generator Lovol Genset China Brand Generating Silent Type

Quick Details:

After-sales Service: After Sales Service and Guarantee
Warranty: 12 Months or 1200 Hours
Type: Self-Starting Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
WT-L165
Output Type
AC Three Phase
Speed
Speed
Conditions of Use
Land Use
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
AC Rotating Exciter
Output
400/230V 380/220V 440/220V 415/240V 480/277V
Phase
Single or Three Phase
Frequency
50Hz/60Hz
Engine Speed
1500rpm/1800rpm
Battery Volatge
12V/24V
Aspiration Engine Type
Turbocharged
Cooling System
Water Cooled
Governing Type
Electrical Starting GAC
Compress Ratio
17:1
Voltage Regulator
AVR Auto Voltage Regulator
Voltage Regulation Maintanined
Within 0.5%
Alternator
Bruxhless, Self Exciting, 100% Copper
Insulation Class
Class “H”
Auto Transfter Switch
Optional ATS
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Including Wooden Package
Specification
2300x980x1500MM
Trademark
WINTPOWER
Origin
China
HS Code
85021200
Production Capacity
8000

Product Description

Diesel Power Generator Lovol Genset China Brand Generating 100kVA 70kVA 150kVA Silent TypeQuick DetailsLovol diesel generator, Lovol Generating set, Lovol Genset, 200kva Lovol generator, 250kva Lovol generator, 150kva Lovol generator, 40kva Lovol generator, 50kva Lovol generator, 70kw Lovol generator, Lovol power generator, Lovol generator parts, Open type Lovol generator, Silent Lovol generator, Lovol power station, Weichai diesel generator, Low price Genset, Cheap Perkin generatorChina brand generator, generator price list China

WT-L LOVOL SERIES SPECIFICATION 50HZ @ 1500RPM
Genset Model 50HZ PF=0.8 400/230V 3Phase 4Wire Engine specification Genset canopy data Genset open data
Prime Power Standby Power Engine Model Stamford Alternator Leroy Somer Alternator Wintpower Alternator Dimention(MM) Dimention(MM)
KVA/KW KVA/KW
WT-L27 20/25 22/27 1003G PI 144E TAL-A40-G WT184F 2100x930x1200 1600x850x1130
WT-L34 25/31 27/34 1003G PI 144G TAL-A42-C WT184G 2100x930x1200 1600x850x1130
WT-L47 34/43 37/47 1003TG PI 144K TAL-A42-F WT224C 2100x930x1200 1650x850x1130
WT-L55 40/50 45/55 1003TG UCI224D TAL-A42-G WT224D 2400x930x1200 1810x850x1130
WT-L69 50/63 55/69 1004TG UCI224E TAL-A42-H WT224E 2500x930x1200 2050x850x1130
WT-L80 58/72 64/80 1004TG UCI224F TAL-A44-C WT224F 2500x930x1200 2050x900x1130
WT-L96 70/88 77/96 1006TG1A UCI224G TAL-A44-D WT224G 2800x1000x1450 2300x900x1330
WT-L110 80/100 88/110 1006TG2A UCI274C TAL-A44-D WT274C 2800x1000x1450 2250x900x1330
WT-L125 90/114 100/125 1006TAG1A UCI274D TAL-A44-E WT274D 3000x1100x1500 2250x900x1370
WT-L133 97/121 107/133 1006TAG1A UCI274E TAL-A44-E WT274E 3000x1100x1500 2400x900x1370
WT-L151 110/138 121/151 1006TAG UCI274E TAL-A44-H WT274E 3000x1100x1500 2400x900x1370
WT-L165 120/150 132/165 1106C-P6TAG2 UCI274F TAL-A44-J WT274F 3250x1250x1650 2550x950x1420
WT-L179 130/163 143/179 1106C-P6TAG3 UCI274F TAL-A44-K WT274F 3250x1250x1650 2550x950x1420
WT-L200 146/183 160/200 1106C-PATAG4 UCI274G TAL-A46-B WT274G 3250x1250x1650 2600x950x1420
WT-L LOVOL SERIES SPECIFICATION 60HZ @ 1800RPM
Genset Model 60HZ PF=0.8 440/220V 3Phase 4Wire Engine specification Genset canopy data Genset open data
Prime Power Standby Power Engine Model Stamford Alternator Leroy Somer Alternator Wintpower Alternator Dimention(MM) Dimention(MM)
KVA/KW KVA/KW
WT-L27 20/25 22/27 1003G PI 144E TAL-A40-G WT184E 2100x930x1200 1600x850x1130
WT-L41 26/33 29/41 1003G PI 144F TAL-A42-C WT184F 2100x930x1200 1600x850x1130
WT-L55 40/50 44/55 1003TG PI 144K TAL-A42-G WT224C 2100x930x1200 1650x850x1130
WT-L69 44/55 48/69 1003TG UCI224D TAL-A42-G WT224D 2500x930x1200 1930x850x1130
WT-L66 50/63 55/69 1004TG UCI224D TAL-A42-H WT224D 2500x930x1200 2050x850x1130
WT-L104 67/83 73/104 1004TG UCI224F TAL-A44-C WT224F 2500x930x1200 2050x900x1130
WT-L93 70/88 77/96 1006TG1A UCI224F TAL-A44-C WT224F 2800x1000x1450 2300x900x1330
WT-L110 80/100 88/110 1006TG1A UCI274C TAL-A44-D WT224G 2800x1000x1450 2250x900x1330
WT-L125 90/114 100/125 1006TG2A UCI274C TAL-A44-E WT274C 3000x1100x1500 2250x900x1370
WT-L133 97/121 107/133 1006TG2A UCI274D TAL-A44-E WT274C 3000x1100x1500 2250x900x1370
WT-L150 110/138 121/151 1006TAG1A UCI274D TAL-A44-H WT274D 3000x1100x1500 2250x900x1370
WT-L165 120/150 132/165 1006TAG UCI274E TAL-A44-H WT274D 3000x1100x1500 2250x900x1370
WT-L184 134/168 147/184 1106C-P6TAG2 UCI274E TAL-A44-K WT274E 3250x1250x1650 2550x950x1420
WT-L234 150/188 165/234 1106C-P6TAG3 UCI274F TAL-A46-A WT274F 3250x1250x1650 2550x950x1420
WT-L255 163/204 181/255 1106C-PATAG4 UCI274G TAL-A46-A WT274G 3250x1250x1650 2600x950x1420

A.STANDARD SUPPLY:1.Brand new CCEC/DCEC, PERKINS, DEUTZ, DOOSAN, YUCHAI, KUBOTA, RICARDO, YANGDONG, water cooled diesel engine.2.Brand new STAMFORD, LEROY SOMER or WINT single bearing 3 phase brushless alternator with 100% copper, IP23 and H insulation class.3. Standard 50ºC radiator with safety guard, engine driven fan mounted on skid4. DEEPSEA, COMAP, SMARTGEN controller brand with Auto/Manual start and AMF function5. DELIXI, CHINT or ABB branded MCCB circuit breaker mounted.6. Heavy-duty fabricated steel based frame with convenient lifting, forklift pockets7. Complete set mounted on a based frame with anti-vibration mountings.8. Industrial 9 dB muffler exhaust system with blexible connects and bellows.9. Based frame with fuel, oil and coolant drain cocks for easy maintenance.10. 12/24V DC electric start system with free maintaining battery & floating battery charger.11. Standard with built-in fuel tank for 8 hours running. Canopy noise levels @7 meters with 70 dB12. Test report of generator, set of drawings and manuals. CE, ISO9001 approvedΔ OPTIONAL SUPPLY: 1.Weatherproof canopy / Soundproof canopy / Trailer-mounted2.Engine / Alternator Pre-heaters3.Auto load sharing & synchronizing panel4.Build-in ATS (Auto start & stop Main Failure (AMF)5.Large 12/24 hours fuel tank6.Power output socketsΔTESTING ITEMSWintpower factory inspection: the test items before delivery are mainly as follows:1.Parts faults testing2.Fuel tank pressure testing3.Bolt tightening torque testing4.Painting thickness testing5.Voltage bearing and insulation testing6.The noise level is tested by requested7.loadingtest range 25% 50% 75% 100% 110% 75% 50% 25% 0%ΔWintpower Silent typeDiesel Generator, advantagesas follows:1. Integrated interface with humanized and practicablydesign2. Super silentmaterial and treatment reach 70dBA@1M full load3. Steel material thickness2MM to 4MM,cut and fold by CNC4. New safe door handle, updated lock, bottom forkliftand top lift5. Aviation outtake connectorad operation LED light6. Free maintenance battery with floating charger8. 8-24hoursbase fuel tank with electrical fuel indicator9. Powder coating canopies afterchemistry treatmentDiesel Power Generator Lovol Genset China Brand Generating 100kVA 70kVA 150kVA Silent TypeDiesel Power Generator Lovol Genset China Brand Generating 100kVA 70kVA 150kVA Silent TypeDiesel Power Generator Lovol Genset China Brand Generating 100kVA 70kVA 150kVA Silent TypeDiesel Power Generator Lovol Genset China Brand Generating 100kVA 70kVA 150kVA Silent TypeDiesel Power Generator Lovol Genset China Brand Generating 100kVA 70kVA 150kVA Silent TypeDiesel Power Generator Lovol Genset China Brand Generating 100kVA 70kVA 150kVA Silent TypeDiesel Power Generator Lovol Genset China Brand Generating 100kVA 70kVA 150kVA Silent TypeDiesel Power Generator Lovol Genset China Brand Generating 100kVA 70kVA 150kVA Silent TypeDiesel Power Generator Lovol Genset China Brand Generating 100kVA 70kVA 150kVA Silent TypeDiesel Power Generator Lovol Genset China Brand Generating 100kVA 70kVA 150kVA Silent TypeDiesel Power Generator Lovol Genset China Brand Generating 100kVA 70kVA 150kVA Silent TypeΔFAQWhat’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .ΔWINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useΔWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
