Hechai Diesel Power Generator Set Dg Genset 550kVA 750kVA

Hechai Diesel Power Generator Set Dg Genset 550kVA 750kVA

Quick Details:

After-sales Service: After Sales Service and Guarantee
Warranty: 12 Months or 1200 Hours
Type: Self-Starting Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
WT-H750
Output Type
AC Three Phase
Speed
Speed
Conditions of Use
Land Use
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
AC Rotating Exciter
Genset Output
400/230V 380/220V 440/220V 415/240V 480/277V
Phase
Single or Three Phase
Frequency
50Hz/60Hz
Engine Speed
1500rpm/1800rpm
Battery Volatge
12V/24V
Aspiration Engine Type
Turbocharged
Cooling System
Water Cooled
Governing Type
Electrical Starting GAC
Compress Ratio
17.0:1
Alternator
Brushless, Self Exciting, 100% Copper
Voltage Regulaor
AVR Auto Voltage Regulator
Voltage Regulation Maintanined
Within 0.5%
Insulation Class
Class “H”
Auto Transfter Switch
Optional ATS
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Including Wooden Package
Specification
5500x1300x1850MM
Trademark
WINTPOWER
Origin
China
HS Code
85021310
Production Capacity
8000

Product Description

Hechai Diesel Power Generator Set Dg Genset 550kVA Tbd234V12-1A 625kVA Tbd234V12-1b 688kVA Tbd604bl6-2A 700kVA Tbd604bl6-2A 750kVA Tbd604bl6-2bQuick DetailsHechai diesel generator, Hechai Generating set, Hechai Genset, 2000kva Hechai generator, 1500kva Hechai generator, 1800kva Hechai generator, 2500kva Hechai generator, 1000kwa Hechai generator, 2000kw Hechai generator, Hechai power generator, Hechai generator parts, Open type Hechai generator, Silent Hechai generator, Hechai power station, Weichai diesel generator, Low price Genset, Cheap diesel generatorChina brand generator, generator price list China

WT-H HECHAI DEUTZ SERIES SPECIFICATION 50HZ @ 1500RPM
Genset Model 50HZ PF=0.8 400/230V 3Phase 4Wire Engine specification
Standby Power Prime Power Engine Model Leroy SomerAlternator Stamford Alternator Wintpower Alternator
KW KW
WT-H250 200 180kw TBD234V6-1A LSA46.2L6 UCD274J WT274L-180N
WT-H275 220 200kw TBD234V6-1B LSA46.2L6 UCD274K WT274L-200N
WT-H350 280 250kw TBD234V8-1A LSA46.2VL12 HCI444ES WT314M-260N
WT-H388 313 280kw TBD234V8-1B LSA47.2VS1 HCI444E WT314L-280N
WT-H413 330 300kw TBD314V8-1A LSA47.2VS2 HCI444FS WT314L-300N
WT-H550 440 400kw TBD234V12-1A LSA47.2M7 HCI544D WT354S-400N
WT-H625 500 450kw TBD234V12-1B LSA47.2L9 HCI544E WT354S-450N
WT-H688 550 500kw TBD604BL6-2A LSA49.1S4A HCI544F-S WT354M-500N
WT-H700 560 520kw TBD604BL6-2A LSA49.1S4 HCI544F WT354M-520N
WT-H750 600 550kw TBD604BL6-2B LSA49.1M6 LVI634B WT354L-560N
WT-H825 660 600kw TBD62OL6-2A LSA49.1M65 LVI634B WT355L-600N
WT-H900 720 640kw TBD62OL6-2B LSA49.1M75 LVI634C WT400S-640N
WT-H1000 800 720kw TBD620V8-2C LSA49.1L10 LVI634D WT400M-720N
WT-H1100 880 800kw TBD620V8-2A LSA49.1L11 LVI634E WT400L-800N
WT-H1250 1000 900kw TBD620V8-2B LSA50.2M6 LVI634F WT400L-900N
WT-H1375 1100 1000kw TBD620V12-2A LSA50.2M6 LVI634G WT400L-1000N
WT-H1650 1320 1200kw TBD620V12-2B LSA50.2L8 PI734C WT400L-1200N
WT-H1850 1500 1350KW TBD620V12-2C LSA51.2S55 PI734D WT450M-1350N
WT-H2200 1760 1600kw TBD620V16-2A LSA51.2 M60 PI734F WT450L-1650N
WT-H2500 2000 1800kw TBD620V16-2B LSA51.2VL85 * WT500L-1800N
WT-H HECHAI DEUTZ SERIES SPECIFICATION 60HZ @ 1800RPM
Genset Model 60HZ PF=0.8 440/220V 3Phase 4Wire Engine specification
Standby Power Prime Power Engine Model Leroy SomerAlternator Stamford Alternator Wintpower Alternator
KW KW
WT-H275 220kw 200kw TBD234V6-2A LSA46.2L6 UCD274J WT274L-180N
WT-H388 310kw 280kw TBD234V8-2A LSA46.2VL12 HCI444D WT314M-260N
WT-H450 360kw 320kw TBD314V8-2A LSA47.2VS2 HCI444E WT314L-280N
WT-H550 440kw 400kw TBD234V12-2A LSA47.2S4 HCI544C WT354S-360N
WT-H688 550kw 500kw TBD604BL6-3A LSA47.2M7 HCI544E WT354S-450N
WT-H850 680kw 620kw TBD62OL6-3A LSA49.1M6 HCI544F WT354L-560N
WT-H1237 1000kw 900kw TBD620V8-3A LSA49.1L11 LVI634E WT400L-800N
WT-H1750 1400KW 1300KW TBD620V12-3A LSA50.2L8 PI734B WT450M-1350N
WT-H2500 2000kw 1800kw TBD620V16-3A LSA51.2M60 PI734E WT500L-1800N

A.STANDARD SUPPLY:1.Brand new CCEC/DCEC, DEUTZ, DOOSAN, YUCHAI, KUBOTA, RICARDO, YANGDONG, water cooled diesel engine.2.Brand newSTAMFORD, LEROY SOMER or WINTsingle bearing 3 phase brushless alternator with 100% copper, IP23 and H insulation class.3. Standard 50ºC radiator with safety guard, engine driven fan mounted on skid4. DEEPSEA, COMAP, SMARTGEN controller brand with Auto/Manual start and AMF function5. DELIXI, CHINT or ABBbranded MCCB circuit breaker mounted.6. Heavy-duty fabricated steel based frame with convenient lifting, forklift pockets7. Complete set mounted on a based frame with anti-vibration mountings.8. Industrial 9 dB muffler exhaust system with blexible connects and bellows.9. Based frame with fuel, oil and coolant drain cocks for easy maintenance.10. 12/24V DC electric start system with free maintaining battery & floating battery charger.11. Standard with built-in fuel tank for 8 hours running. Canopy noise levels @7 meters with 70 dB12. Test report of generator, set of drawings and manuals. CE, ISO9001 approvedΔ OPTIONAL SUPPLY: 1.Weatherproof canopy / Soundproof canopy / Trailer-mounted2.Engine / Alternator Pre-heaters3.Auto load sharing & synchronizing panel4.Build-in ATS (Auto start & stop Main Failure (AMF)5.Large 12/24 hours fuel tank6.Power output socketsΔTESTING ITEMSWintpower factory inspection: the test items before delivery are mainly as follows:1.Parts faults testing2.Fuel tank pressure testing3.Bolt tightening torque testing4.Painting thickness testing5.Voltage bearing and insulation testing6.The noise level is tested by requested7.loadingtest range 25% 50% 75% 100% 110% 75% 50% 25% 0%ΔWintpower Silent typeDiesel Generator, advantagesas follows:1. Integrated interface with humanized and practicablydesign2. Super silentmaterial and treatment reach 70dBA@1M full load3. Steel material thickness2MM to 4MM,cut and fold by CNC4. New safe door handle, updated lock, bottom forkliftand top lift5. Aviation outtake connectorad operation LED light6. Free maintenance battery with floating charger8. 8-24hoursbase fuel tank with electrical fuel indicator9. Powder coating canopies afterchemistry treatmentHechai Diesel Power Generator Set Dg Genset 550kVA Tbd234V12-1A 625kVA Tbd234V12-1b 688kVA Tbd604bl6-2A 700kVA Tbd604bl6-2A 750kVA Tbd604bl6-2bHechai Diesel Power Generator Set Dg Genset 550kVA Tbd234V12-1A 625kVA Tbd234V12-1b 688kVA Tbd604bl6-2A 700kVA Tbd604bl6-2A 750kVA Tbd604bl6-2bHechai Diesel Power Generator Set Dg Genset 550kVA Tbd234V12-1A 625kVA Tbd234V12-1b 688kVA Tbd604bl6-2A 700kVA Tbd604bl6-2A 750kVA Tbd604bl6-2bHechai Diesel Power Generator Set Dg Genset 550kVA Tbd234V12-1A 625kVA Tbd234V12-1b 688kVA Tbd604bl6-2A 700kVA Tbd604bl6-2A 750kVA Tbd604bl6-2bHechai Diesel Power Generator Set Dg Genset 550kVA Tbd234V12-1A 625kVA Tbd234V12-1b 688kVA Tbd604bl6-2A 700kVA Tbd604bl6-2A 750kVA Tbd604bl6-2bHechai Diesel Power Generator Set Dg Genset 550kVA Tbd234V12-1A 625kVA Tbd234V12-1b 688kVA Tbd604bl6-2A 700kVA Tbd604bl6-2A 750kVA Tbd604bl6-2bHechai Diesel Power Generator Set Dg Genset 550kVA Tbd234V12-1A 625kVA Tbd234V12-1b 688kVA Tbd604bl6-2A 700kVA Tbd604bl6-2A 750kVA Tbd604bl6-2bHechai Diesel Power Generator Set Dg Genset 550kVA Tbd234V12-1A 625kVA Tbd234V12-1b 688kVA Tbd604bl6-2A 700kVA Tbd604bl6-2A 750kVA Tbd604bl6-2bHechai Diesel Power Generator Set Dg Genset 550kVA Tbd234V12-1A 625kVA Tbd234V12-1b 688kVA Tbd604bl6-2A 700kVA Tbd604bl6-2A 750kVA Tbd604bl6-2bHechai Diesel Power Generator Set Dg Genset 550kVA Tbd234V12-1A 625kVA Tbd234V12-1b 688kVA Tbd604bl6-2A 700kVA Tbd604bl6-2A 750kVA Tbd604bl6-2bHechai Diesel Power Generator Set Dg Genset 550kVA Tbd234V12-1A 625kVA Tbd234V12-1b 688kVA Tbd604bl6-2A 700kVA Tbd604bl6-2A 750kVA Tbd604bl6-2bΔFAQWhat’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .ΔWINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useΔWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
