Diesel Power Generator Kubota DG Genset with Soundproof Type Generation

Diesel Power Generator Kubota DG Genset with Soundproof Type Generation

Quick Details:

After-sales Service: After Sales Service and Guarantee
Warranty: 12 Months or 1200 Hours
Type: Self-Starting Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
WT-KU15
Output Type
AC Three Phase
Speed
Speed
Conditions of Use
Land Use
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
AC Rotating Exciter
Genset Output
400/230V 380/220V 440/220V 415/240V 480/277V
Phase
Single or Three Phase
Frequency
50Hz/60Hz
Engine Speed
1500rpm/1800rpm
Battery Volatge
12V/24V
Aspiration Engine Type
Turbocharged
Cooling System
Water Cooled
Governing Type
Electrical Starting GAC
Compress Ratio
17:1
Voltage Regulatior
AVR Auto Voltage Regulator
Voltage Regulation Maintanined
Within 0.5%
Alternator
Brushless, Self Exciting, 100% Copper
Insulation Class
Class “H”
Auto Transfter Switch
Optional ATS
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Including Wooden Package
Specification
6000x2500x2500MM
Trademark
WINTPOWER
Origin
China
HS Code
85021100
Production Capacity
8000

Product Description

Diesel Power Generator Kubota D G 10kVA 12kVA 15kVA 18kVA 20kVA 25kVA 30kVA 40kVA Genset with Soundproof Type GenerationQuick DetailsKUBOTA diesel generator, KUBOTA Generating set, KUBOTA Genset, 15KVA KUBOTAgenerator, 25kva KUBOTA generator, KUBOTA power generator, KUBOTA generatorparts, Open type KUBOTA generator, Silent KUBOTA generator, KUBOTA power station,Japanese Engine genset, Japanese power diesel generator

KT-KU KUBOTA SERIES SPECIFICATION 50HZ @ 1500RPM PF=0.8 400/230V 3Phase 4Wire
GENSET MODEL RATED POWER STANDBY POWER ENGINE STAMFORD ALTERNATOR LEROY SOMER ALTERNATOR WINT ALTERNATOR DIMENSION
KW/KVA KW/KVA MODEL MODEL MODEL MODEL SILENT TYPE OPEN TYPE
WT-KU8 5/6.3 6/7.5 D905 PI 044D TAL-A40-C WT164A 1700x850x1050 1250x750x1000
WT-KU9 6.7/8.4 7.4/9.2 D1105 PI 044E TAL-A40-C WT164A 1700x850x1050 1250x750x1000
WT-KU12 9/11.3 10/12.4 V1505 PI 044F TAL-A40-C WT164B 1850x850x1050 1400x750x1000
WT-KU14 10.4/13.0 11.4/14.3 D1703 PI 044G TAL-A40-C WT164C 1850x850x1050 1400x750x1000
WT-KU21 15/18 16.5/20.6 V2203 PI 144D TAL-A40-F WT184E 2000x890x1050 1550x800x1000
WT-KU23 17/21.3 19/23 V2003-T PI 144E TAL-A40-G WT184F 2000x890x1050 1550x800x1000
WT-KU30 22/27.5 24/30 V3300 PI 144G TAL-A42-C WT184F 2150x930x1150 1600x800x1080
WT-KU38 27.8/34.8 30.5/38 V3300-T PI 144H TAL-A42-E WT184H 2150x930x1150 1650x800x1080
KT-KU KUBOTA SERIES SPECIFICATION 60HZ @ 1800RPM PF=0.8 440/220V 3Phase 4Wire
GENSET TYPE RATED STANDBY ENGINE STAMFORD ALTERNATOR LEROY SOMER ALTERNATOR WINT ALTERNATOR DIMENSION
KW/KVA KW/KVA MODEL MODEL MODEL MODEL SILENT TYPE OPEN TYPE
WT-KU8 6/7.5 6.6/8.3 D905 PI 044D TAL-A40-C WT164A 1700x850x1050 1250x750x1000
WT-KU11 8/10.0 8.8/11.0 D1105 PI 044E TAL-A40-C W164A 1700x850x1050 1250x750x1000
WT-KU15 10.8/13.5 12/15.0 V1505 PI 044F TAL-A40-C WT164C 1850x850x1050 1400x750x1000
WT-KU17 12/15.0 13/16.5 D1703 PI 044F TAL-A40-D WT164C 1850x850x1050 1400x750x1000
WT-KU23 17/21.2 19/23 V2203 PI 144D TAL-A40-F WT164D 2000x890x1050 1550x800x1000
WT-KU28 20.6/25.7 23/28 V2003-T PI 144E TAL-A40-G WT184E 2000x890x1050 1550x800x1000
WT-KU38 27.5/34.4 30/38 V3300 PI 144G TAL-A42-E WT184G 2150x930x1150 1600x800x1080
WT-KU47 34/42.5 37/47 V3300-T PI 144J TAL-A42-F WT184H 2150x930x1150 1650x800x1080

A.STANDARD SUPPLY:1.Brand new CCEC/DCEC, PERKINS, DEUTZ, DOOSAN, YUCHAI, KUBOTA, RICARDO, YANGDONG,water cooled diesel engine.2.Brand newSTAMFORD, LEROY SOMER or WINTsingle bearing 3 phase brushless alternator with 100% copper, IP23 and H insulation class.3. Standard 50ºC radiator with safety guard, engine driven fan mounted on skid4. DEEPSEA, COMAP, SMARTGEN controller brand with Auto/Manual start and AMF function5. DELIXI, CHINT or ABBbranded MCCB circuit breaker mounted.6. Heavy-duty fabricated steel based frame with convenient lifting, forklift pockets7. Complete set mounted on a based frame with anti-vibration mountings.8. Industrial 9 dB muffler exhaust system with blexible connects and bellows.9. Based frame with fuel, oil and coolant drain cocks for easy maintenance.10. 12/24V DC electric start system with free maintaining battery & floating battery charger.11. Standard with built-in fuel tank for 8 hours running. Canopy noise levels @7 meters with 70 dB12. Test report of generator, set of drawings and manuals. CE, ISO9001 approvedΔ OPTIONAL SUPPLY: 1.Weatherproof canopy / Soundproof canopy / Trailer-mounted2.Engine / Alternator Pre-heaters3.Auto load sharing & synchronizing panel4.Build-in ATS (Auto start & stop Main Failure (AMF)5.Large 12/24 hours fuel tank6.Power output socketsΔTESTING ITEMSWintpower factory inspection: the test items before delivery are mainly as follows:1.Parts faults testing2.Fuel tank pressure testing3.Bolt tightening torque testing4.Painting thickness testing5.Voltage bearing and insulation testing6.The noise level is tested by requested7.loadingtest range 25% 50% 75% 100% 110% 75% 50% 25% 0%ΔWintpower Silent typeDiesel Generator, advantagesas follows:1. Integrated interface with humanized and practicablydesign2. Super silentmaterial and treatment reach 70dBA@1M full load3. Steel material thickness2MM to 4MM,cut and fold by CNC4. New safe door handle, updated lock, bottom forkliftand top lift5. Aviation outtake connectorad operation LED light6. Free maintenance battery with floating charger8. 8-24hoursbase fuel tank with electrical fuel indicator9. Powder coating canopies afterchemistry treatmentDiesel Power Generator Kubota D G 10kVA 12kVA 15kVA 18kVA 20kVA 25kVA 30kVA 40kVA Genset with Soundproof Type GenerationDiesel Power Generator Kubota D G 10kVA 12kVA 15kVA 18kVA 20kVA 25kVA 30kVA 40kVA Genset with Soundproof Type GenerationDiesel Power Generator Kubota D G 10kVA 12kVA 15kVA 18kVA 20kVA 25kVA 30kVA 40kVA Genset with Soundproof Type GenerationDiesel Power Generator Kubota D G 10kVA 12kVA 15kVA 18kVA 20kVA 25kVA 30kVA 40kVA Genset with Soundproof Type GenerationDiesel Power Generator Kubota D G 10kVA 12kVA 15kVA 18kVA 20kVA 25kVA 30kVA 40kVA Genset with Soundproof Type GenerationDiesel Power Generator Kubota D G 10kVA 12kVA 15kVA 18kVA 20kVA 25kVA 30kVA 40kVA Genset with Soundproof Type GenerationDiesel Power Generator Kubota D G 10kVA 12kVA 15kVA 18kVA 20kVA 25kVA 30kVA 40kVA Genset with Soundproof Type GenerationDiesel Power Generator Kubota D G 10kVA 12kVA 15kVA 18kVA 20kVA 25kVA 30kVA 40kVA Genset with Soundproof Type GenerationDiesel Power Generator Kubota D G 10kVA 12kVA 15kVA 18kVA 20kVA 25kVA 30kVA 40kVA Genset with Soundproof Type GenerationDiesel Power Generator Kubota D G 10kVA 12kVA 15kVA 18kVA 20kVA 25kVA 30kVA 40kVA Genset with Soundproof Type GenerationDiesel Power Generator Kubota D G 10kVA 12kVA 15kVA 18kVA 20kVA 25kVA 30kVA 40kVA Genset with Soundproof Type GenerationΔFAQWhat’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .ΔWINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useΔWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
