Cummins Kta19 Engine Part 3803598 3801007 2888893

Cummins Kta19 Engine Part 3803598 3801007 2888893

Quick Details:

Conditions
of Use:
Car Type, Trailer Type, Marine, Land Use
Usage: Emergency Crew, Standby Unit, Common Units
Output Type: AC Three Phase
Cooling
Method:
Water Cooling
Installation
Method:
Fixed
Generator
Type:
Diesel Generator
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
Engine Speed
1500rpm/1800rpm
Frequency
50Hz/60Hz
Aspiration Engine Typ
Turbocharged
Cooling System
Water Cooled
Governing Type
Electrical Starting GAC
Compress Ratio
17.0:1
Delivery
by Shipping or by Airway
Part Type
Brand New
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Packing with Carton
Specification
500*400*600
Trademark
Cummins
Origin
China
HS Code
850300
Production Capacity
8000

Product Description

Cummins Kta19 Engine Part 3014668 4095097 206973 3065790 3066877 205492 3017961 3803598 3801007 2888893

Cummins CCEC KTA19 SERIES MAINTENACE SPARE PARTS
Item Part Name QTY Part Number Maintenance Peried
1 CARTRIDGE,LUB 12 LF670 250hrs 500hrs 2250hrs,3600hrs
2 ELEMENT,LUBOIL FILTER 12 LF777
3 FILTER,FUEL 24 FS1212
4 CORROSION RESISTOR 3 WF2076
5 CLEANER,AIR 3 AF872
6 BELT,V 3 3002203
7 BELT,V 6 206996
8 TURBOCHARGER ,KIT 1 3545647
9 BEARING,CONNECTING 2 205840
10 SET,MAIN BEARING 1 AR12270
11 VALVE,EXHAUST 4 207241
12 VALVE,INTAKE 4 3035110
13 INSERT,VALVE EXHAUST 4 205093
14 INSERT,INTAKE VALVE 4 3026296
15 COLLET,VALVE 16 205091
16 RETAINER,VALVE SPRING 8 205094
17 GUIDE,VALVE SPRING 8 3001663
18 SPRING,VALVE 8 3629006
19 GULVE,VALVE STEM 8 3202210
20 INJECTOR 6 3016676
21 NOZZLE,PISTION COOLING 6 3007517
22 THERMOSTAT 1 3076489
23 OIL PRESSURE sensor 1 3015237
24 water temp sensor 2 3015238
25 speed, sensor 1 3034572
26 BUSHING 1 3043909
27 BUSHING 1 3002834
28 OIL PUMP 1 3047549
29 MOTOR,STARING 1 3021038
30 ALTERNATOR 1 3016627
31 WATER,PUMP 1 3098960
32 IMPELLER,WATER PUMP 1 205243
33 TURBOCHARGER 1 3523850
34 PISTON,ENGINE 6 3096682
35 PIN,PISTON 6 4095009
36 PISTON,ENGINE 6 4089500
37 RING,REATING 6 205269
38 LINER,CYLINDER 6 4009220
39 SEAL,DREVICE 6 205115
40 SEAL,O RING 12 3011076
41 SEAL,O RING 12 3014668
42 CORE,COOLER 1 4095097
43 GASKET,COOLER ELEMENT 4 206973
44 GASKET 1 3065790
45 CAMSHAFT 1 3066877
46 ROD,PUSH 6 205492
47 ROD,PUSH 6 3017961
48 SET,UPPER ENGINE GSK 1 3803598
49 SET,LOWER ENGINE GSK 1 3801007
50 thrust washers 24
51 KTAA19-G6A BELT TENSIONER 2888893
