Portable Diesel Generator Home Use Gasoline Generator Outdoor Gasoline

Portable Diesel Generator Home Use Gasoline Generator Outdoor Gasoline

Quick Details:

After-sales Service: After Sales Service and Guarantee
Warranty: 12 Months or 1200 Hours
Type: Self-Starting Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Air Cooled
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
WT-CLR5500
Output Type
AC Three Phase
Speed
Speed
Conditions of Use
Land Use
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
AC Rotating Exciter
Genset Output
400/230V, 380/220V, 440/220V, 415/240V, 480/277V
Phase
One Phase or Three Phase
Engine Speed
3000rpm/3600rpm
Battery Volatge
12V/24V
Governing Type
Electrical Starting GAC
Alternator
Brushless, Self Exciting, 100% Copper
Voltage Regulator
AVR Auto Voltage Regulator
Insulation Class
Class “H”
Quality Standard
ISO9001, ISO14001, CE, EPA
Transport Package
Plastic Seaworth Including Wooden Package
Specification
1000x800x750MM
Trademark
WINTPOWER
Origin
China
HS Code
85021100
Production Capacity
8000

Product Description

Portable Diesel Generator off Grid Diesel Generator Home Use Diesel Generator Portable Gasoline Generator Outdoor Generator Gasoline Generator Set

WT Portable Diesel Generator Set Spefication
Open Type
Model WT3800CL WT5000CL WT7500CL WT10000CL WT11000ME
AC output (V) 120/240 120/240 120/240 120/240 120/240
Frequency (Hz) 50/60 50/60 50/60 50/60 50/60
Max. Power (kW) 3.8 5 7 8.5 10.5
Rated power (kW) 3.5 4.5 6.5 8 9.5
DC output (V/A) 12/6 12/6 12/6 12/6 12/6
Engine Power (HP) 7.5 16 16 18 20
Manual Starting System hand start hand start hand start hand start Electric start with18AH battery
Displacement (cc) 223 420 420 458.5 614
Engine speed (rpm) 3000/3600 3000/3600 3000/3600 3000/3600 3000/3600
Lube oil capacity (L) 0.6 1.4 1.4 1.5 1.5
Fuel tank capacity (L) 15 25 25 25 25
Continuous operation hour (h) 6.2 7.8 6.5 4.8 3.7
Noise (7 meters away) dB(A) 69 75 76 80 77
Net weight (kg) 46 62 71 80 140
PRICE for WHEELS AND HANDLE $9 $10 $10 $10 $0
Electric start with battery $23 $32 $32 $32 $0
Optional design
Soundproof Silent Type
Model WT6500S WT7500S WT9000S WT10000S WT11000S WT13000S
AC output (V) 120/240 120/240 120/240 120/240 120/240 120/240
Frequency (Hz) 50/60 50/60 50/60 50/60 50/60 50/60
Max. Power (kW) 5.5 6.5 7 8 10.5 11
Rated power (kW) 5 6 6.5 7.5 9.5 10.5
DC output (V/A) 12/6 12/6 12/6 12/6 12/6 12/6
Engine Power (HP) 10 10 12 14 20 22
Manual Starting System Electric start with18AH battery Electric start with18AH battery Electric start with18AH battery Electric start with18AH battery Electric start with18AH battery Electric start with18AH battery
Displacement (cc) 418 418 435 498 870 954
Engine speed (rpm) 3600 3600 3600 3600 3600 3600
Lube oil capacity (L) 1.6 1.6 1.7 1.7 2 2.5
Fuel tank capacity (L) 15 15 15 15 30 30
Continuous operation hour (h) 8 8 8 8 8 8
Noise (7 meters away) dB(A) 70 70 70 70 70 70
Net weight (kg) 165 166 167 168 255 260
Packing dimensions(mm) 930*540*800 930*540*800 930*540*800 930*540*800 1220*760*980 1220*760*980
20 FCL (sets) 48 48 48 48 26 26
PRICE for WHEELS AND HANDLE included

A.STANDARD SUPPLY:1.Brand new CCEC/DCEC, MITSUBISHI, DEUTZ, DOOSAN, YUCHAI, KUBOTA, RICARDO, YANGDONG,water cooled diesel engine.2.Brand newSTAMFORD, LEROY SOMER or WINTsingle bearing 3 phase brushless alternator with 100% copper, IP23 and H insulation class.3. Standard 50ºC radiator with safety guard, engine driven fan mounted on skid4. DEEPSEA, COMAP, SMARTGEN controller brand with Auto/Manual start and AMF function5. DELIXI, CHINT or ABBbranded MCCB circuit breaker mounted.6. Heavy-duty fabricated steel based frame with convenient lifting, forklift pockets7. Complete set mounted on a based frame with anti-vibration mountings.8. Industrial 9 dB muffler exhaust system with blexible connects and bellows.9. Based frame with fuel, oil and coolant drain cocks for easy maintenance.10. 12/24V DC electric start system with free maintaining battery & floating battery charger.11. Standard with built-in fuel tank for 8 hours running. Canopy noise levels @7 meters with 70 dB12. Test report of generator, set of drawings and manuals. CE, ISO9001 approvedΔ OPTIONAL SUPPLY: 1.Weatherproof canopy / Soundproof canopy / Trailer-mounted2.Engine / Alternator Pre-heaters3.Auto load sharing & synchronizing panel4.Build-in ATS (Auto start & stop Main Failure (AMF)5.Large 12/24 hours fuel tank6.Power output socketsΔTESTING ITEMSWintpower factory inspection: the test items before delivery are mainly as follows:1.Parts faults testing2.Fuel tank pressure testing3.Bolt tightening torque testing4.Painting thickness testing5.Voltage bearing and insulation testing6.The noise level is tested by requested7.loadingtest range 25% 50% 75% 100% 110% 75% 50% 25% 0%ΔWintpower Silent typeDiesel Generator, advantagesas follows:1. Integrated interface with humanized and practicablydesign2. Super silentmaterial and treatment reach 70dBA@1M full load3. Steel material thickness2MM to 4MM,cut and fold by CNC4. New safe door handle, updated lock, bottom forkliftand top lift5. Aviation outtake connectorad operation LED light6. Free maintenance battery with floating charger8. 8-24hoursbase fuel tank with electrical fuel indicator9. Powder coating canopies afterchemistry treatmentPortable Diesel Generator off Grid Diesel Generator Home Use Diesel Generator Portable Gasoline Generator Outdoor Generator Gasoline Generator SetPortable Diesel Generator off Grid Diesel Generator Home Use Diesel Generator Portable Gasoline Generator Outdoor Generator Gasoline Generator SetPortable Diesel Generator off Grid Diesel Generator Home Use Diesel Generator Portable Gasoline Generator Outdoor Generator Gasoline Generator SetPortable Diesel Generator off Grid Diesel Generator Home Use Diesel Generator Portable Gasoline Generator Outdoor Generator Gasoline Generator SetPortable Diesel Generator off Grid Diesel Generator Home Use Diesel Generator Portable Gasoline Generator Outdoor Generator Gasoline Generator SetPortable Diesel Generator off Grid Diesel Generator Home Use Diesel Generator Portable Gasoline Generator Outdoor Generator Gasoline Generator SetPortable Diesel Generator off Grid Diesel Generator Home Use Diesel Generator Portable Gasoline Generator Outdoor Generator Gasoline Generator SetPortable Diesel Generator off Grid Diesel Generator Home Use Diesel Generator Portable Gasoline Generator Outdoor Generator Gasoline Generator SetPortable Diesel Generator off Grid Diesel Generator Home Use Diesel Generator Portable Gasoline Generator Outdoor Generator Gasoline Generator SetPortable Diesel Generator off Grid Diesel Generator Home Use Diesel Generator Portable Gasoline Generator Outdoor Generator Gasoline Generator SetPortable Diesel Generator off Grid Diesel Generator Home Use Diesel Generator Portable Gasoline Generator Outdoor Generator Gasoline Generator SetΔFAQWhat’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .ΔWINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useΔWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
