Deutz Diesel Power Generator Set Dg Genset 575kVA 620kVA 760kVA 825kVA 600kw

Deutz Diesel Power Generator Set Dg Genset 575kVA 620kVA 760kVA 825kVA 600kw

Quick Details:

After-sales Service: After Sales Service and Guarantee
Warranty: 12 Months or 1200 Hours
Type: Self-Starting Diesel Generator
Installation Method: Fixed
Stroke: Four Stroke
Cooling Method: Water Cooling
Customization:

Product Detail

Product Tags

Basic Info.

Model NO.
WT-DE825
Output Type
AC Three Phase
Speed
Speed
Conditions of Use
Land Use
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
AC Rotating Exciter
Genset Output
400/230V 380/220V 440/220V 415/240V 480/277
Phase
Single or Three Phase
Frequency
50Hz/60Hz
Engine Speed
1500rpm/1800rpm
Battery Volatge
12V/24V
Aspiration Engine Type
Turbocharged
Cooling System
Water Cooled
Governing Type
Electrical Starting GAC
Compress Ratio
17:1
Voltage Regulator
AVR Auto Voltage Regulator
Voltage Regulation Maintanined
Within 0.5%
Alternator
Brushless, Self Exciting, 100% Copper
Insulation Class
Class “H”
Auto Transfter Switch
Optional ATS
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Including Wooden Package
Specification
6000x2500x2500MM
Trademark
WINTPOWER
Origin
China
HS Code
85021200
Production Capacity
8000

Product Description

Deutz Diesel Power Generator Set Dg Genset 575kVA Bf8m1015cp-Lag4 620kVA Bf8m1015cp-Lag5 760kVA Hc12V132zl-Lag1a 825kVA Hc12V132zl-Lag2a 600kwQuick DetailsDeutz diesel generator, Deutz Generating set, Deutz Genset, 500kva Deutz generator,250kva Deutz generator, 400kva Deutz generator, 825kva Deutz generator, Deutz powergenerator, Deutz generator parts, Open type Deutz generator, Silent Deutz generator,Deutz power station

WT-D DEUTZ SERIES SPECIFICATION 50HZ @ 1500RPM
Genset Model 50HZ PF=0.8 400/230V 3Phase 4Wire Engine Model cyl displacement Battery Vol. Max power Governor Open Type Dimension
Standby Power Prime Power Cons 100%(L/H)
KVA/KW KVA/KW L V KW L×W×H(MM) Weight KG
WT-DE70 70/55 60/50 9 BF4M2012 4 4.03 24 65 mech. 1930*750*1400 825
WT-DE90 90/70 75/60 11 BF4M2012C 4 4.03 24 79 mech. 1930*750*1400 825
WT-DE100 100/80 90/70 12 BF4M1013E 4 4.76 24 93 mech. 2070*1000*1420 1030
WT-DE125 125/100 110/90 14 BF4M1013EC 4 4.76 24 108 elec. 2300*900*1700 1150
WT-DE150 150/120 140/110 19 BF4M1013FC 4 4.76 24 140 elec. 2300*910*1700 1200
WT-DE175 175/140 160/130 23 BF6M1013EC 6 7.15 24 164 elec. 2400*1200*1780 1400
WT-DE225 225/180 200/160 28 BF6M1013FCG2 6 7.15 24 198 elec. 2500*1250*1800 1450
WT-DE240 240/190 210/170 31 BF6M1013FCG3 6 7.15 24 218 elec. 2500*1250*1800 1450
WT-DE250 250/200 225/180 28 BF6M1015-LAGA 6V 11.9 24 231 mech. 2700*1450*1950 2850
WT-DE275 275/220 250/200 31 TCD8.0 6V 11.9 24 250 elec. 3000*1500*2000 3300
WT-DE275 275/220 250/200 31 BF6M1015C-LAG1A 6V 11.9 24 250 elec. 3000*1500*2000 3300
WT-DE310 310/250 290/230 36 BF6M1015C-LAG2A 6V 11.9 24 285 elec. 3100*1650*2015 3350
WT-DE340 340/275 310/250 39 BF6M1015C-LAG3A 6V 11.9 24 314 elec. 2800*1450*1950 3100
WT-DE390 390/310 350/280 43 BF6M1015C-LAG4 6V 11.9 24 345 elec. 2800*1450*1950 3100
WT-DE400 400/320 360/290 45 BF6M1015CP-LAG 6V 11.9 24 365 elec. 2800*1450*1950 3200
WT-DE450 450/360 410/330 51 BF8M1015C-LAG1A 8V 15.9 24 418 elec. 3300*1440*2240 3700
WT-DE500 500/400 450/360 56 BF8M1015C-LAG2 8V 15.9 24 448 elec. 3100*1650*2015 3350
WT-DE510 510/410 460/370 58 BF8M1015CP-LAG1A 8V 15.9 24 459 elec. 3100*1650*2015 3350
WT-DE540 540/430 490/390 61 BF8M1015CP-LAG2 8V 15.9 24 490 elec. 3120*1650*2015 3350
WT-DE560 560/450 510/410 64 BF8M1015CP-LAG3 8V 15.9 24 509 elec. 3120*1650*2015 3350
WT-DE575 575/460 525/420 65 BF8M1015CP-LAG4 8V 15.9 24 530 elec. 3120*1650*2015 3500
WT-DE620 620/495 560/450 70 BF8M1015CP-LAG5 8V 15.9 24 560 elec. 3200*1650*2015 3650
WT-DE760 760/605 690/550 84 HC12V132ZL-LAG1A 12V 23.8 24 670 elec. 3600*1450*1950 4500
WT-DE825 825/660 750/600 92 HC12V132ZL-LAG2A 12V 23.8 24 740 elec. 4500*1500*2600 5000
WT-DE DEUTZ SERIES SPECIFICATION 60HZ @ 1800RPM
Genset Model 60HZ PF=0.8 440/220V 3Phase 4Wire Engine specification Genset canopy data Genset open data
Standby Power Prime Power Cons 100%(L/H) Engine Model Cyl. Gov. Displacement(L) Dimention(MM) weight(KG) Dimention(MM) Weight(KG)
KVA/KW KVA/KW
WT-DE77 77/62 70/56 18.9 BF4M2012 4L Elec 4.04 2670*1080*1865 1650 1870*980*1500 970
WT-DE96 96/77 87.5/70 22.7 BF4M2012C 4L Elec 4.04 2670*1080*1865 1850 1960*980*1500 1040
WT-DE105 105/84 95/76 28 BF4M1013E 4L Elec 4.76 2900*1080*2000 1950 2140*980*1700 1180
WT-DE105 105/84 95/76 28 BF4M1013EC 4L Elec 4.76 2900*1080*2000 1950 2140*980*1700 1180
WT-DE125 125/100 113/90 28 BF4M1013EC 4L Elec 4.76 2900*1080*2000 1950 2090*980*1700 1220
WT-DE150 150/120 138/110 36.5 BF4M1013FC 4L Elec 7.15 2900*1080*2000 2100 2280*980*1700 1310
WT-DE193 193/154 175/140 41.8 BF6M1013EC 6L Elec 7.15 3500*1080*2120 2500 2500*980*1700 1590
WT-DE240 240/192 220/176 52.7 BF6M1013FCG2 6L Elec 7.15 3750*1280*1915 2900 2640*1150*1790 1710
WT-DE270 270/216 245/196 60.2 BF6M1013FCG3 6L Elec 7.15 3750*1280*1915 2950 2640*1150*1790 1760
WT-DE275 275/220 250/200 58 BF6M1015-LAGB 6V Elec 11.906 3600*1400*2150 2980 2500*1250*2150 2193
WT-DE300 300/240 275/220 64 TCD8.0 6V Elec 11.906 3800*1600*2150 3508 2630*1410*2150 2228
WT-DE300 300/240 275/220 64 BF6M1015C-LAG1B 6V Elec/M 11.906 3800*1600*2150 3508 2630*1410*2150 2228
WT-DE330 330/264 300/240 70 BF6M1015C-LAG2B 6V Elec/M 11.906 3800*1600*2150 3508 2730*1410*2150 2423
WT-DE375 375/300 338/270 79 BF6M1015C-LAG3B 6V Elec/M 11.906 3800*1600*2150 3508 2730*1410*2150 2503
WT-DE500 500/400 450/360 106 BF8M1015C-LAG1B 8V Elec/M 15.874 4350*1750*2450 5300 3100*1560*2150 3263
WT-DE525 525/420 475/380 112 BF8M1015CP-LAG1B 8V Elec/M 15.874 4350*1750*2450 5302 3100*1560*2150 3263

A.STANDARD SUPPLY:1.Brand new CCEC/DCEC, DEUTZ, DOOSAN, YUCHAI, KUBOTA, RICARDO, YANGDONG,water cooled diesel engine.2.Brand newSTAMFORD, LEROY SOMER or WINTsingle bearing 3 phase brushless alternator with 100% copper, IP23 and H insulation class.3. Standard 50ºC radiator with safety guard, engine driven fan mounted on skid4. DEEPSEA, COMAP, SMARTGEN controller brand with Auto/Manual start and AMF function5. DELIXI, CHINT or ABBbranded MCCB circuit breaker mounted.6. Heavy-duty fabricated steel based frame with convenient lifting, forklift pockets7. Complete set mounted on a based frame with anti-vibration mountings.8. Industrial 9 dB muffler exhaust system with blexible connects and bellows.9. Based frame with fuel, oil and coolant drain cocks for easy maintenance.10. 12/24V DC electric start system with free maintaining battery & floating battery charger.11. Standard with built-in fuel tank for 8 hours running. Canopy noise levels @7 meters with 70 dB12. Test report of generator, set of drawings and manuals. CE, ISO9001 approvedΔ OPTIONAL SUPPLY: 1.Weatherproof canopy / Soundproof canopy / Trailer-mounted2.Engine / Alternator Pre-heaters3.Auto load sharing & synchronizing panel4.Build-in ATS (Auto start & stop Main Failure (AMF)5.Large 12/24 hours fuel tank6.Power output socketsΔTESTING ITEMSWintpower factory inspection: the test items before delivery are mainly as follows:1.Parts faults testing2.Fuel tank pressure testing3.Bolt tightening torque testing4.Painting thickness testing5.Voltage bearing and insulation testing6.The noise level is tested by requested7.loadingtest range 25% 50% 75% 100% 110% 75% 50% 25% 0%ΔWintpower Silent typeDiesel Generator, advantagesas follows:1. Integrated interface with humanized and practicablydesign2. Super silentmaterial and treatment reach 70dBA@1M full load3. Steel material thickness2MM to 4MM,cut and fold by CNC4. New safe door handle, updated lock, bottom forkliftand top lift5. Aviation outtake connectorad operation LED light6. Free maintenance battery with floating charger8. 8-24hoursbase fuel tank with electrical fuel indicator9. Powder coating canopies afterchemistry treatmentDeutz Diesel Power Generator Set Dg Genset 575kVA Bf8m1015cp-Lag4 620kVA Bf8m1015cp-Lag5 760kVA Hc12V132zl-Lag1a 825kVA Hc12V132zl-Lag2a 600kwDeutz Diesel Power Generator Set Dg Genset 575kVA Bf8m1015cp-Lag4 620kVA Bf8m1015cp-Lag5 760kVA Hc12V132zl-Lag1a 825kVA Hc12V132zl-Lag2a 600kwDeutz Diesel Power Generator Set Dg Genset 575kVA Bf8m1015cp-Lag4 620kVA Bf8m1015cp-Lag5 760kVA Hc12V132zl-Lag1a 825kVA Hc12V132zl-Lag2a 600kwDeutz Diesel Power Generator Set Dg Genset 575kVA Bf8m1015cp-Lag4 620kVA Bf8m1015cp-Lag5 760kVA Hc12V132zl-Lag1a 825kVA Hc12V132zl-Lag2a 600kwDeutz Diesel Power Generator Set Dg Genset 575kVA Bf8m1015cp-Lag4 620kVA Bf8m1015cp-Lag5 760kVA Hc12V132zl-Lag1a 825kVA Hc12V132zl-Lag2a 600kwDeutz Diesel Power Generator Set Dg Genset 575kVA Bf8m1015cp-Lag4 620kVA Bf8m1015cp-Lag5 760kVA Hc12V132zl-Lag1a 825kVA Hc12V132zl-Lag2a 600kwDeutz Diesel Power Generator Set Dg Genset 575kVA Bf8m1015cp-Lag4 620kVA Bf8m1015cp-Lag5 760kVA Hc12V132zl-Lag1a 825kVA Hc12V132zl-Lag2a 600kwDeutz Diesel Power Generator Set Dg Genset 575kVA Bf8m1015cp-Lag4 620kVA Bf8m1015cp-Lag5 760kVA Hc12V132zl-Lag1a 825kVA Hc12V132zl-Lag2a 600kwDeutz Diesel Power Generator Set Dg Genset 575kVA Bf8m1015cp-Lag4 620kVA Bf8m1015cp-Lag5 760kVA Hc12V132zl-Lag1a 825kVA Hc12V132zl-Lag2a 600kwDeutz Diesel Power Generator Set Dg Genset 575kVA Bf8m1015cp-Lag4 620kVA Bf8m1015cp-Lag5 760kVA Hc12V132zl-Lag1a 825kVA Hc12V132zl-Lag2a 600kwDeutz Diesel Power Generator Set Dg Genset 575kVA Bf8m1015cp-Lag4 620kVA Bf8m1015cp-Lag5 760kVA Hc12V132zl-Lag1a 825kVA Hc12V132zl-Lag2a 600kwΔFAQWhat’s your power range of Generators?Answer:We can offer the range from 5kva~3000kva.2.What’s your delivery time?Answer:Generally,we can delivery in 15-35days after confirmation of order.3.What’s your payment?Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipmentor L/C at sight.But based on some special project and special order,we can do somethingsupporton payment item.4.What’s your warranty?One year or 1000hours (accordingto whichever reach first) from Ex-Factory date5.What’s your MOQ?Answer:We accept power generator MOQ is 1set .ΔWINTPOWER Service SystemCustomer-focused traditional service better and better service levels worldwide-network ServiceConcepts:Ensure that customers at ease using for WINTPOWERProducts Serving the customers, WINTPOWERgains trust .Work together with Customers During the service period, WINTPOWERdo best firstly and protects customers’interests.In case of failure to use the generator, WINTPOWERhelp customer untilthey know how to useΔWINTPOWER Service PrinciplesCustomer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
